High Performance Vector Control/Torque Control Inverter User Manual
Chapter 6 Parameter Description 87
Display of operation panel
Unit’s digit
AI1:
0: Determine the reference frequency
(P6.01 ~ P6.04) by Curve 1
1: Determine the reference frequency
(P6.05 ~ P6.08) by Curve 2
2: Per unit value determined by curve 3
(P6.09 to P6.12);
3: Per unit value determined by curve
4(P6.13 to P6.20);
4: Calibration by curve is not necessary
Tens place
AI2: The same as above
Hundreds
place
AI3: The same as above
Thousands
place
DI: The same as above
Curve 1 and curve 2 can be used to directly realize the corresponding relationship between analog value
and setup frequency, while curve 3 and curve 4 can be used to convert the externally input analog value
into analog values inside the inverter. The analog value selection is determined by P6.21.
Note:
The running and stop display parameters AI1 ~ AI3 and DI determined by P2.02 and P2.03 all
refer to the analog values inside the inverter, of which DI input is calculated on the basis of
10V corresponding to the maximum input pulse frequency P5.10.
When current analog value input is selected, please refer to Fig.6-20.
When “Calibration by curve is not necessary” is selected, the maximum analog input or
maximum input pulse frequency corresponds to the maximum output frequency P0.11 or
100% per-unit value of the inverter.
Since the using methods of curve 1 and curve 2 are identical, Curve 1 is described as an example here.
Both curve 1 and curve 2 can be used in process open loop analog frequency reference, and the running
frequency of the inverter can be determined by the analog values AI1, AI2 and AI3 and DI pulse
frequency reference. The conversion relationship between analog value and setup frequency is as
shown in the figures below:
P6.01 Curve 1 input point A0
0.0 ~110.0 %(0.0%)
P6.02 Reference frequency f0 corresponding to curve 1 input point A0 0.00~ 300.00 Hz(0.00Hz)
P6.03 Curve 1 input point A1
0.0 ~110.0 %(100.0%)
P6.04 Reference frequency f1 corresponding to curve 1 input point A1 0.00 ~ 300.00 Hz(50.00Hz)
P6.05 Curve 2 input point A0
0.0 ~110.0 %(0.0%)
P6.06 Reference frequency f0 corresponding tocurve 2 input point A0
0.00 ~300.00 Hz(0.00%)
P6.07 Curve 2 input point A1
0.0 ~110.0 %(100.0%)
P6.08 Reference frequency f1 corresponding to curve 2 input point A1 0.00 ~ 300.00 Hz(50.00Hz)
