High Performance Vector Control/Torque Control Inverter User Manual
114
Chapter 6 Parameter Description
PC.04 master-slave mode:
0: SCIA is slave mode and SCIB is slave mode;
1: SCIA is master mode and SCIB is slave mode;
2: SCIA is slave mode and SCIB is master mode.
PC.05 master to slave operation address (set by master), position for writing slave function code to
master setting frequency:
0: P0.05 1: P8.00 2: P8.01
The inverter provides two communication ports. SCIA is a port connecting with operation panel, and
SCIB is used terminal for 485+ and 485-.
In common applications, the inverter operates under slave mode (PC.04=0) and responses to external
instructions.
Master mode: To active sent data to outside, which is often applied when multi-machines operate
synchronously. When selecting master mode, one unit in a group of units often is set as a master to
transfer operating frequency instructions to other units. When the slave receives frequency instructions
from the master, it will store these instructions at the position of function code specified by PC.05. For
example, if open loop digital frequency is given, adopt P0.05 as frequency reference and set PC.05=0.
If inverter master mode is set for SCIA/SCIB and operation panel has been inserted, the operation panel
will take priority of controlling, and the function of inverter as master mode will lose effect automatically.
Pull out the operation panel, after 10 seconds the inverter will return back to master mode.
PC.06 slave setting frequency proportional coefficient (set by the slave):
The parameter is only valid for the slave and is used to set the slave to receive correction coefficient
specified by the master.
Slave setting=PC.06 × master reference.
6.14 Vector Control 2 Parameters (Group Pd)
This group of functions is only valid for vector control 2. They are invalid for Vector control 1.
The switching between speed control and torque control can be realized through this function code.
0: Speed Control Mode
The motor action is controlled by the speed command, and the internal ASR is valid. The speed control
mode shall be used together with the drive torque limiting value Pd.08 and braking torque limiting value
Pd.09.
1: Torque control mode
At this time, the internal ASR is invalid, and the motor action is controlled by the analog reference torque
PC.04 Master-slave mode
0~2(0)
PC.05 Operation Address from master to slave (set by master) 0~2(0)
PC.06 Slave setting frequency proportional coefficient (set by slave)
0.00~10.00(1.00)
Pd.00
Speed/torque control
0~1(0)
