KSB Movitec VV04/05 [20/60] High pressure pumps

KSB Movitec LHS04/06 [20/60] High pressure pumps

Movitec; 6B; n = 2900 rpm

K95000600/2

0 2 4 6 8 10

Q [m³/h]

0 10 20 30 40

Q [US.gpm]

0 10 20 30

Q [IM.gpm]

100

150

200

250

H [m]

200

400

600

800

H [ft]

0.0 0.5 1.0 1.5 2.0 2.5

Q [l/s]

NPSH

[m]

NPSH

[ft]

Eta [%]

0.2

0.05

P [kW]

0.1

0.3

P [hp]

0 2 4 6 8 10

Q [m³/h]

6/26 5,5kW

6/24 5,5 kW

6/22 5,5kW

6/20 5,5kW

6/18 4,0kW

6/16 4,0kW

6/14 3,0kW

6/12 3,0kW

6/11 3,0kW

6/10 2,2kW

6/9 2,2kW

6/8 2,2kW

6/7 1,5kW

6/6 1,5kW

6/5 1,1kW

6/4 1,1kW

6/3 0,75kW

6/2 0,37kW

St=1

St = Number of stages

The power input P is indicated per stage
