User Manual
Chapter 1. Commands for ACL 29
www.qtech.ru
access-list 10(used 1 time(s))
Number ACL10, 0 time to be used
access-list 10 deny any-source
Deny any IP packets to pass
access-list 100(used 1 time(s))
Nnumber ACL10, 1 time to be used
access-list 100 deny ip any-source
any-destination
Deny IP packet of any source IP address
and destination address to pass
access-list 100 deny tcp any-source
any-destination
Deny TCP packet of any source IP
address and destination address to pass
access-list 1100 permit any-source-
mac any-destination-mac tagged-eth2
14 2 0800
Permit tagged-eth2 with any source
MAC addresses and any destination
MAC addresses and the packets whose
15th and 16th byte is respectively 0x08 ,
0x0 to pass
access-list 3100 permit any-source-
mac any-destination-mac udp any-
source s-port 100 any-destination d-
port 40000
Deny the passage of UDP packets with
any source MAC address and destination
MAC address, any source IP address and
destination IP address, and source port
100 and destination interface 40000
1.28 show access-group
Command: show access-group in (interface {Ethernet | Ethernet IFNAME})
Functions: Display the ACL binding status on the port.
Parameters: IFNAME, Port name.
Default: None.
Command Mode: Admin and Configuration Mode.
Usage Guide: When not assigning interface names, all ACL tied to port will be revealed.
Examples:
Switch#show access-group
interface name: Ethernet 1/0/1
IP Ingress access-list used is 100, traffic-statistics Disable.
interface name: Ethernet1/0/2
IP Ingress access-list used is 1, packet(s) number is 11110.
