Disassembly/Inspection and Service

14 690 01 Rev. G KohlerEngines.com

WARNING

Before working on engine or equipment, disable engine as

follows: 1) Disconnect spark plug lead(s). 2) Disconnect

negative (–) battery cable from battery.

Accidental Starts can cause severe injury or

death.

Disconnect and ground spark plug lead(s)

before servicing.

External Engine Components

Engine Cover and

Insert

B Engine Cover C

Engine Cover and

Retractable Start

D Retractable Starter

E Blower Housing F Mufer Guard G Mufer H Air Cleaner Base

I Breather Hose J Paper Element K Air Cleaner Cover L Precleaner
