Specifi cations
8 24 690 37 Rev. DKohlerEngines.com
TORQUE SPECIFICATIONS
3,5
CV682 CV732 CV742 CV752
Stator
Mounting Screw 6.2 N·m (55 in. lb.)
Valve Cover
Yellow O-Ring Style Cover Fastener
w/Integral Metal Spacers 6.2 N·m (55 in. lb.)
CLEARANCE SPECIFICATIONS
3
CV682 CV732 CV742 CV752
Camshaft
End Play 0.076/0.127 mm (0.0030/0.0050 in.)
Running Clearance 0.025/0.063 mm (0.0010/0.0025 in.)
Bore I.D.
New
Max. Wear Limit
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
Bearing Surface O.D.
New
Max. Wear Limit
19.962/19.975 mm (0.7859/0.7864 in.)
19.959 mm (0.7858 in.)
Connecting Rod
Connecting Rod-to-Crankpin Running Clearance
New
Max. Wear Limit
0.030/0.055 mm (0.0012/0.0022 in.)
0.070 mm (0.0028 in.)
Connecting Rod-to-Crankpin Side Clearance 0.26/0.63 mm (0.0102/0.0248 in.)
Connecting Rod-to-Piston Pin Running Clearance 0.015/0.028 mm (0.0006/0.0011 in.)
Piston Pin End I.D.
New
Max. Wear Limit
17.015/17.023 mm (0.6699/0.6702 in.)
17.036 mm (0.6707 in.)
Crankcase
Governor Cross Shaft Bore I.D.
New
Max. Wear Limit
8.025/8.075 mm (0.3159/0.3179 in.)
8.088 mm (0.3184 in.)
Crankshaft
End Play (free) 0.070/0.590 mm (0.0028/0.0230 in.)
Bore (in crankcase)
New
Max. Wear Limit
40.965/41.003 mm (1.6128/1.6143 in.)
41.016 mm (1.6148 in.)
Crankshaft to Sleeve Bearing (crankcase)
Running Clearance-New 0.03/0.09 mm (0.0012/0.0035 in.)
Bore (in oil pan)
New 40.987/40.974 mm (1.6136/1.6131 in.)
Crankshaft Bore (in oil pan)-to-Crankshaft
Running Clearance-New 0.039/0.074 mm (0.0015/0.0029 in.)
Flywheel End Main Bearing Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
40.913/40.935 mm (1.6107/1.6116 in.)
40.84 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
