Specifi cations
924 690 37 Rev. D KohlerEngines.com
CLEARANCE SPECIFICATIONS
3
CV682 CV732 CV742 CV752
Crankshaft (continued)
Oil Pan End Main Bearing Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
40.913/40.935 mm (1.6107/1.6116 in.)
40.84 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
Connecting Rod Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
35.955/35.973 mm (1.4156/1.4163 in.)
35.94 mm (1.415 in.)
0.018 mm (0.0007 in.)
0.025 mm (0.0010 in.)
T.I.R.
PTO End, Crank in Engine
Entire Crank, in V-Blocks
0.279 mm (0.0110 in.)
0.10 mm (0.0039 in.)
Cylinder Bore
Bore I.D.
New 80.000/
80.025 mm
(3.1496/
3.1506 in.)
82.988/83.013 mm
(3.2672/3.2682 in.)
Max. Wear Limit 80.065 mm
(3.1522 in.)
83.051 mm
(3.2697 in.)
Max. Out-of-Round 0.12 mm (0.0047 in.)
Max. Taper 0.05 mm (0.0020 in.)
Cylinder Head
Max. Out-of-Flatness 0.076 mm
(0.003 in.)
0.1 mm (0.004 in.)
Governor
Governor Cross Shaft-to-Crankcase
Running Clearance 0.025/0.126 mm (0.0009/0.0049 in.)
Cross Shaft O.D.
New
Max. Wear Limit
7.949/8.000 mm (0.3129/0.3149 in.)
7.936 mm (0.3124 in.)
Governor Gear Shaft-to-Governor Gear
Running Clearance
0.015/0.140 mm (0.0006/0.0055 in.)
Gear Shaft O.D.
New
Max. Wear Limit
5.990/6.000 mm (0.2358/0.2362 in.)
5.977 mm (0.2353 in.)
Ignition
Spark Plug Gap 0.76 mm (0.030 in.)
Module Air Gap 0.203/0.305 mm (0.008/0.012 in.)
3
Values are in Metric units. Values in parentheses are English equivalents.
