Tools and Aids

1324 690 30 Rev. D KohlerEngines.com

Certain quality tools are designed to help you perform specifi c disassembly, repair, and reassembly procedures. By

using these tools, you can properly service engines easier, faster, and safer! In addition, you’ll increase your service

capabilities and customer satisfaction by decreasing engine downtime.

Here is a list of tools and their source.

SEPARATE TOOL SUPPLIERS

Kohler Tools

Contact your local Kohler source of

SE Tools

415 Howard St.

Design Technology Inc.

768 Burr Oak Drive

Alcohol Content Tester

For testing alcohol content (%) in reformulated/oxygenated fuels.

Kohler 25 455 11-S

Camshaft Endplay Plate

For checking camshaft endplay.

SE Tools KLR-82405

Camshaft Seal Protector (Aegis)

For protecting seal during camshaft installation.

SE Tools KLR-82417

Cylinder Leakdown Tester

For checking combustion retention and if cylinder, piston, rings, or valves are worn.

Individual component available:

Adapter 12 mm x 14 mm (Required for leakdown test on XT-6 engines)

Kohler 25 761 05-S

Design Technology Inc.

DTI-731-03

Rectifi er-Regulator Tester (120 V AC/60Hz)

Kohler 25 761 20-S

Dealer Tool Kit (International)

Complete kit of Kohler required tools.

Components of 25 761 42-S

Ignition System Tester

Cylinder Leakdown Tester

Oil Pressure Test Kit

Rectifi er-Regulator Tester (240 V AC/50Hz)

Kohler 25 761 42-S

Kohler 25 455 01-S

Kohler 25 761 05-S

Kohler 25 761 06-S

Kohler 25 761 41-S

Digital Vacuum/Pressure Tester

For checking crankcase vacuum.

Design Technology Inc.

DTI-721-01

Components of 24 761 01-S

Fuel Pressure Tester

Noid Light

90° Adapter

In-line "T" Fitting

Code Plug, Red Wire

Code Plug, Blue Wire

Shrader Valve Adapter Hose

Design Technology Inc.

Flywheel Puller

For properly removing fl ywheel from engine.

SE Tools KLR-82408
