English | 13
Bosch Power Tools 1 609 929 X35 | (28.2.11)
Magnet
Keep the magnet 15 away from
cardiac pacemakers. The magnet
generates a field that can impair
the function of cardiac pace-
makers.
f Keep the magnet 15 away from magnetic
data medium and magnetically-sensitive
equipment. The effect of the magnetic can
lead to irreversible data loss.
Product Description and
Specifications
While reading the operating instructions, unfold
the fold-out page with the illustration of the in-
spection camera and leave it open.
Intended Use
The digital inspection camera is suitable for in-
specting hard to reach locations or dark areas.
After mounting the provided accessories to the
camera head, it is also suitable for moving and
removing small and light objects (e.g., small
screws).
The digital inspection camera may not be used
for medicinal purposes. It is also not suitable for
repairing pipe clogs or pulling in cables.
Product Features
The numbering of the product features refers to
the illustration of the inspection camera on the
graphics page.
1 Hand unit
2 Increase-brightness button “+”
3 On/Off button
4 Reduce-brightness button “–”
5 Display
6 Camera cable
7 Camera head
8 Camera lens
9 Illumination light in camera head
10 Battery*
11 Battery unlocking button
12 Camera cable, extension*
13 Socket sleeve of camera connection
14 Camera connection
15 Magnet
16 Hook
17 Mirror
18 Video output socket
19 Video cable
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
Technical Data
Digital Inspection
Camera
GOS 10,8 V-LI
Professional
Article number
3 601 B41 000
Rated voltage
V= 10.8
Operating temperature
°C 20...+65
Storage temperature
(hand unit without
battery)
°C 30...+80
Relative humidity
%595
1)
Smallest bending
radius of camera cable
mm 120
Diameter of camera
head
mm 17/9.5
Depth-of-field range of
camera lens
mm 38
Display size
mm 68.6
Display resolution
320 x 240
Format of video output
NTSC
Operating life time,
approx.
h15
Weight according to
EPTA-Procedure
01/2003
kg 0.68
Dimensions (length x
width x height)
mm 166 x 66 x 45
1) Free of moisture condensation
Please observe the article number on the type plate of
your inspection camera. The trade names of individual
inspection cameras can vary.
