KSB MegaCPK 050-032-160 [10/30] Centrifugal pumps with shaft seal

Size

Bearing bracket

Impeller Shaft diameter in seal

chamber

Diameter of shaft

protecting sleeve

Volute casing design

18)

Heatable casing

Impeller outlet width

Free passage

Impeller inlet diameter

Impeller diameter

Number of vanes

Dry shaft

Wet shaft

Bearing

Coupling

Gland packing

Mechanical seal

Max. Min.

Northern Asia /

Europe

Americas

Northern Asia / Europe /

Southern Asia

Americas

[mm] [mm] [mm] [mm] [mm]

[mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm]

200-150-315 CS80 40 26,9 192 334 264 6 60 65 65 80 48 70 65 65 E ✘

200-150-400 CS80 33 23,8 191 419 330 6 60 65 65 80 48 70 65 65 E -

200-150-500 CS80 23 19,1 190 504 400 7 60 65 65 80 48 70 65 65 D -

200-200-250 CS80 62 37,2 190 260 200 5 60 65 65 80 48 70 65 65 E -

250-200-315 CS80 50 20,8 222 320 260 7 60 65 65 80 48 70 65 65 E ✘

250-200-400 CS80 40 18,4 222 404 320 8 60 65 65 80 48 70 65 65 D ✘

250-200-500 CS80 32 20,6 222 504 400 7 60 65 65 80 48 70 65 65 D -

300-250-315 CS80 73 26,7 270 324 260 6 60 65 65 80 48 70 65 65 D ✘

18)

E = single volute, D = double volute

Centrifugal Pumps with Shaft Seal

Standardised Chemical Pumps

MegaCPK
