Part No. Comprising Description
433.02 433.02 Mechanical seal, complete
452.01 452.01 Gland follower
454.01 454.01 Stuffing box ring
458.01 458.01 Lantern ring
461.01 461.01 Gland packing
463.01 463.01 Drip plate
471.01 471.01 Seal cover
502.01
24)
502.01 Casing wear ring
502.02
24)
502.02 Casing wear ring
503.01
24)
503.01 Impeller wear ring
503.02
24)
503.02 Impeller wear ring
507.01 507.01 Thrower
507.02
30)
507.02 Thrower
524.01 524.01 Shaft protecting sleeve
550.01 550.01 Disc
550.23 550.23 Disc
550.24
31)
550.24 Disc
550.25
31)
550.25 Disc
550.74 550.74 Disc
554.98 554.98 Washer
561.03 561.03 Grooved pin
636.02
31)
636.02 Lubricating nipple
636.03
31)
636.03 Lubricating nipple
638
32)32)
638 Constant level oiler
642
32)
642 Oil level sight glass
672
32)
672 Vent plug
81-92 81-92 Cover plate
99-9 411.01/.02/.03/.04/.10/.15/31/.32/.46 Joint ring
400.01/02 Gasket
901.04 901.04 Hexagon head bolt
901.30 901.30 Hexagon head bolt
901.31 901.31 Hexagon head bolt
901.32 901.32 Hexagon head bolt
901.98 901.98 Hexagon head bolt
902.15 902.15 Stud
903.46 903.46 Screw plug
914.01 914.01 Hexagon socket head cap screw
914.02 914.02 Hexagon socket head cap screw
920.15 920.15 Hexagon nut
922 922 Impeller nut
932.01 932.01 Circlip
932.02 932.02 Circlip
The relevant version is indicated in the product literature
supplied.
30)
On versions with labyrinth seal only
31)
On grease-lubricated versions only
32)
Not applicable for grease-lubricated versions
