![KSB MegaCPK 200-150-315 [28/30] Megacpk](/views2/1603783/page28/bg1c.png)
Position Code Description
ES Internal circulation with heatable seal cover
EB Internal circulation with heatable seal cover and throttling bush as
quench seal
A "A" casing cover (with conical casing cover)
AQ "A" casing cover with lip seal as quench seal
AD "A" casing cover with throttling bush as quench seal
B Dead-end
BQ Dead-end, with lip seal as quench seal
BD Dead-end, with throttling bush as quench seal
F External flushing
FQ External flushing with lip seal as quench seal
FD External flushing with throttling bush as quench seal
CA Cartridge mechanical seal ("A" casing cover)
CE Cartridge mechanical seal with external circulation
CI Cartridge mechanical seal with internal circulation
CED Cartridge mechanical seal with external circulation and throttling
bush as quench seal
CID Cartridge mechanical seal with internal circulation and throttling
bush as quench seal
CEQ Cartridge mechanical seal with external circulation and lip seal as
quench seal
CIQ Cartridge mechanical seal with internal circulation and lip seal as
quench seal
CQA Cartridge mechanical seal with lip seal as quench seal ("A" casing
cover)
CDA Cartridge mechanical seal with throttling bush as quench seal ("A"
casing cover)
DB Double mechanical seal (back-to-back)
DR Double mechanical seal (back-to-back) with pumping screw
TM Tandem mechanical seals, with barrier fluid and jacket cooling
TR Tandem mechanical seals, outboard with pumping screw
TS Tandem mechanical seals, supplied with barrier fluid pressure
CBA Double cartridge mechanical seal, supplied with barrier fluid
pressure ("A" casing cover)
CTA Double cartridge mechanical seal, with unpressurised quench fluid
("A" casing cover)
CB Double cartridge mechanical seal, supplied with barrier fluid
pressure
CT Double cartridge mechanical seal, with unpressurised quench fluid
26-29 Motor rating
1320 132 kW
0075 7.5 kW
0007 0.75 kW
30 Number of poles
2 2 poles
4 4 poles
6 6 poles
31 Product generation
A Product generation MegaCPK 2012
32-35 PumpDrive
PDB With PumpDrive 1st generation, Basic
PDA With PumpDrive 1st generation, Advanced
PD2 With PumpDrive 2nd generation
PD2E With PumpDrive 2nd generation, Eco
PDS With PumpDrive 1st generation, Advanced, with KSB Supreme
36
PumpMeter
M With PumpMeter
Centrifugal Pumps with Shaft Seal
Standardised Chemical Pumps
28
MegaCPK
