26
10, 15, 22SV SERIES
HYDRAULIC PERFORMANCE TABLE AT 50 Hz, 2 POLES
TABELLA DI PRESTAZIONI IDRAULICHE SERIE 10SV 15SV 22SV 2p 50 Hz
PUMP
TYPE MEI ≥ l
/min 0 83,34 100 133 170 183,34 233 270 330 350 400 430 460 483,33
m
3
/h 0
5,0 6,0 8,0 10,2 11,0 14,0 16,2 19,8 21,0 24,0 25,8 27,6 29,0
kW HP (1)
10SV01 0,75 1 0,70
11,8 11,2 10,9 9,9 8,3 7,6 4,3
10SV02 0,75 1 0,70
23,6 21,9 21,3 19,6 17,0 15,8 10,0
10SV03 1,1 1,5 0,70
35,7 33,0 32,1 29,6 25,8 24,1 16,0
10SV04 1,5 2 0,70
47,7 44,2 43,0 39,9 34,8 32,6 21,7
10SV05 2,2 3 0,70
60,0 56,1 54,7 50,9 44,9 42,2 29,0
10SV06 2,2 3 0,70
71,8 66,8 65,0 60,4 53,1 49,8 33,9
10SV07 3 4 0,70
83,6 78,3 76,2 70,8 62,1 58,3 39,8
10SV08 3 4 0,70
95,3 88,9 86,5 80,1 70,2 65,7 44,5
10SV09 4 5,5 0,70
106,3 100,1 97,5 90,8 80,0 75,1 52,1
10SV10 4 5,5 0,70
118,0 110,8 107,9 100,3 88,2 82,8 57,2
10SV11 4 5,5 0,70
129,6 121,3 118,1 109,6 96,3 90,3 62,1
10SV13 5,5 7,5 0,70
156,0 146,5 142,7 132,6 116,4 109,2 74,3
10SV15 5,5 7,5 0,70
179,5 167,9 163,4 151,6 132,8 124,3 83,9
10SV17 7,5 10 0,70
205,0 193,2 188,5 175,7 154,7 145,2 98,8
10SV18 7,5 10 0,70
216,9 204,2 199,1 185,5 163,2 153,1 104,0
10SV20 7,5 10 0,70
240,6 226,0 220,3 205,0 180,2 168,9 114,3
10SV21 11 15 0,70
253,6 241,0 235,5 220,2 195,0 183,5 127,5
15SV01 1,1 1,5 0,70
14,0 12,9 12,4 12,2 11,3 10,4 8,4 7,6 5,1
15SV02 2,2 3 0,70
28,7 26,7 25,9 25,5 23,9 22,4 18,9 17,4 13,1
15SV03 3 4 0,70
43,3 40,4 39,1 38,6 36,2 33,8 28,7 26,5 20,1
15SV04 4 5,5 0,70
58,4 54,7 53,1 52,5 49,4 46,3 39,7 36,9 28,7
15SV05 4 5,5 0,70
72,7 67,8 65,8 65,0 61,0 57,1 48,7 45,2 34,9
15SV06 5,5 7,5 0,70
87,6 81,5 79,4 78,4 74,1 69,9 60,3 56,3 44,2
15SV07 5,5 7,5 0,70
101,9 94,5 91,9 90,8 85,7 80,6 69,4 64,7 50,5
15SV08 7,5 10 0,70
117,4 110,9 108,0 106,8 100,8 94,9 82,0 76,7 60,6
15SV09 7,5 10 0,70
131,9 124,4 121,0 119,6 112,8 106,1 91,5 85,5 67,4
15SV10 11 15 0,70
147,7 138,8 135,3 133,8 126,7 119,6 103,9 97,4 77,5
15SV11 11 15 0,70
162,3 152,4 148,5 146,8 138,9 131,1 113,8 106,5 84,7
15SV13 11 15 0,70
191,3 179,2 174,5 172,5 163,1 153,7 133,1 124,5 98,6
15SV15 15 20 0,70
222,1 209,9 204,8 202,6 192,2 181,7 158,3 148,5 118,8
15SV17 15 20 0,70
251,6 237,3 231,4 228,9 216,9 205,0 178,4 167,3 133,6
22SV01 1,1 1,5 0,70
14,7 13,5 12,7 12,0 10,4 9,7 7,7 6,3 4,7 3,4
22SV02 2,2 3 0,70
30,4 28,4 27,2 26,0 23,3 22,2 18,9 16,6 13,8 11,5
22SV03 3 4 0,70
45,4 42,2 40,4 38,5 34,5 32,8 27,8 24,2 20,2 16,6
22SV04 4 5,5 0,70
60,9 56,8 54,4 51,9 46,6 44,4 37,9 33,1 27,7 23,0
22SV05 5,5 7,5 0,70
76,0 70,9 67,9 64,9 58,3 55,6 47,4 41,4 34,7 28,8
22SV06 7,5 10 0,70
93,2 88,8 85,7 82,5 75,4 72,4 63,3 56,7 49,1 42,6
22SV07 7,5 10 0,70
108,5 103,1 99,4 95,7 87,2 83,7 73,1 65,3 56,5 48,8
22SV08 11 15 0,70
124,6 119,2 115,2 111,0 101,6 97,7 85,7 77,0 66,9 58,2
22SV09 11 15 0,70
140,1 133,7 129,2 124,4 113,8 109,3 95,8 86,0 74,6 64,8
22SV10 11 15 0,70
155,4 148,2 143,1 137,8 125,9 120,9 105,8 94,8 82,3 71,3
22SV12 15 20 0,70
186,1 178,6 172,9 166,8 152,9 147,0 129,1 115,9 100,7 87,4
22SV14 15 20 0,70
216,6 207,7 200,9 193,7 177,4 170,4 149,4 133,9 116,1 100,6
22SV17 18,5 25 0,70
263,5 252,8 244,7 236,0 216,2 207,8 182,3 163,6 142,0 123,2
10-22sv-2p50-en_b_thHydraulic performances in compliance with ISO 9906:2012 - Grade 3B (ex ISO 9906:1999 - Annex A)
(1) Value referred to the F, T, R, N, V, C, K versions. P version excluded.
H = TOTAL HEAD IN METRES OF COLUMN OF WATER
Q = DELIVERYRATED
POWER
