e-SH SERIES

GENERAL INTRODUCTION

The new and improved Lowara e-SH Series is a high performance stainless steel centrifugal end-suction electro-

pump with single stage, axial flanged suction port, radial flanged discharge, and horizontal shaft.

The e-SH is fully made in AISI 316 stainless steel which makes it suitable for handling water as well as non-

aggressive or moderately aggressive fluids.

The pumps are equipped with intercheangeable mechanical seals, IE3 efficiency motors, and have a back pull-out

design (impeller, bracket and motor can be extracted without disconnecting the pump body from the piping).

3

• Maximum head: up to 110 m for 2 poles range.

up to 27 m for 4 poles range.

• Hydraulic performance compliant with ISO 9906:2012

Grade 3B.

• Fluid temperature range:

- standard version (with FKM* gaskets)

-20 to +120 °C

- versions on request (with EPDM gaskets)

-30 to +120 °C.

• Squirrel cage in short circuit enclosed construction

with external ventilation (TEFC).

• 2-pole and 4-pole ranges.

• IP55 protection degree as motor (EN 60034-5), IPX5

as electro-pump (EN 60529).

• Performances according to EN 60034-1.

• IE3 efficiency level (three-phase 0,75 to 75 kW).

• 155 (F) insulation class.

• Standard voltage:

1 x 220-240 V 50 Hz for power up to 2,2 kW

Extended shaft

Close-coupled by means of an adaptor

bracket with an impeller keyed directly

to the special motor shaft extension.

Frame mounted

Flexible-coupled with bracket, support,

flexing coupling (special version with

choring base.

Stub shaft

Rigid-coupled with a bracket, an adap-

standard motor shaft extension.

Bare shaft pump

motor.

List of the Directives

and the main technical norms

(electric motors)
