Lowara ESHE 25-200/30/P25RSNA [8/120] Esh series identification code

8

Pump Type [3 digits]

[ESH] = series name

Coupling [1 digit]

[ ] = bare shaft

[E]= extended shaft

[S] = stub shaft

[F] = frame mounted

[C] = spacer coupling

Discharge diameter - nominal impeller diameter

e.g. 32-160, 65-160

Motor type [2 digits]

[/P] = PLM

[/S] = SM

[/W] = Weg

[/X] = Other

Motor power [2 to 3 digits]

kW x 10

or

E S H F 6 5 - 1 6 0 / 1 1 0 A / P 2 5 V S N A

Special trimmed Impeller

[blank or 1 digit]

[A] = Trimmed diameter

that doesn’t maximi-

ze motor power

[X] = Trimmed diameter

to meet customer

required duty point

Frequency [2digits]

50 Hz

5W = 3x440-460/- V

60 Hz

6F = 1x220-230 V

6E = 1x200-210 V

6P = 3x220-230/380-400 V

6R = 3x255-277/440-480 V

6V = 3x440-480/- V

6U = 3x380-400/660-690 V

6N = 3x200-208/346-360 V

6T = 3x330-346/575-600 V

[S] = Fabricated Stainless

Steel (1.4404)

[1 digit]

[A] = Ceramic/Carbon/FKM*

[B] = Ceramic/Carbon/EPDM

[2] = SiC/Carbon/FKM*

[4] = SiC/Carbon/EPDM

[W] = SiC/SiC/FKM*

[Z] = SiC/SiC/EPDM

[X] = other configurations

ESH SERIES

IDENTIFICATION CODE

End-suction, electric pump with frame mounted coupling, DN 80 nominal discharge port, 160 mm nominal impeller diameter, 2,2 kW rated motor

power, trimmed impeller, PLM IE3 model, 4-pole, 50 Hz 220-240/380-415 V, fabricated stainless steel casing, cast stainless steel impeller, Ceramic/

Carbon/FKM mechanical seal.

ESH 50-250/D224SSA

End-suction, bare shaft pump, DN 50 nominal discharge port, 250 mm nominal impeller diameter, 224 mm actual impeller diameter, fabricated

stainless steel casing, fabricated stainless steel impeller, Ceramic/Carbon/FKM mechanical seal.

* FPM (old ISO), FKM (ASTM & new ISO)
