7
Applications
The Lowara e-SH Series is suitable for many different applications demanding reliable and efficient products. The
reliability, robustness, and AISI 316 material configuration of the e-SH series makes it ideal for use in aggressive
environments or for pumping of mildly aggressive fluids.
Finally the e-SH series compactness and reliability allows
for use in diverse OEM applications.
The Lowara e-SH Series can be used for the following
Industry applications:
• Process
- Process cooling and Process heating
- Heat recovery
• Water Supply
- Pressure boosting
- Irrigation systems
- Water transfer for green houses
- Liquid transfer with mildly aggressive liquids or
environment.
• Water treatment
- Washing and cleaning
- Water treatment.
• Diverse OEM applications
Benefits
The Lowara e-SH Series permit to achieve the following
benefits:
• Performances: the e-SH pumps are ErP 2015
compliant, equipped with IE3 motors and provide
improved performance vs. the old SH series of pumps. Its AISI 316 material configuration makes it ideal for
pumping mildly aggressive liquids or pumping in aggressive environment. With a standard version designed for
up to PN12 pressure rating, 120 °C maximum fluid temperature, an FKM elastomer, and with easy maintenance,
the e-SH provides the solution to many Industry needs.
• Reliability: the high quality in production, the robust construction and operation, the easily interchangeable
mechanical seals, and wear rings guarantee a continuous operation without faults and a shorter down time for
maintenance.
• Know How: the perfect configuration for an application can be made with the selection tool or with the sup-
port of our industrial experienced employees.
• Pre- and post-sales support
:
we are continuously working close to our customers to help them in selecting
the right pump for the specific application. An improved user-friendly selection software improved with many
selection tools is available on the website, on DVD or on Apps for mobile phones. Experienced engineers are
fully dedicated to big projects for Municipality.
Features
Discharge ports DN25 to DN80.
Wide performance range up to 110 m head and 240 m³/h flow.
Nominal pressure 12 bar.
Wide range of temperatures for pumped liquids: -30°C to +120°C.
Wide range of materials for many different kinds of pumped liquid.
Wide range of voltages.
High performance IE3 motors.
Variable speed by optional HYDROVAR drive.
e-SH SERIES
for INDUSTRY
APPLICATIONS & BENEFITS
