DIMENSIONI E PESI SERIE FCTE 2 poli 50 Hz
PUMP TYPE WEIGHT
BHL k
DNA DNM b1 h1 h2 h3 l1 p x kg
FCTE 40-125/07/D 40 40 245 170 50 120 89 155 250 490 320 452 90 56
FCTE 40-125/11/D 40 40 245 170 50 120 89 155 250 490 320 452 90 58
FCTE 40-160/15/D 40 40 245 170 50 120 89 155 250 490 320 452 90 60
FCTE 40-160/22/C 40 40 245 170 50 120 89 174 250 490 320 487 90 69
FCTE 40-200/40A/P 40 40 348 220 50 190 97 197 360 695 440 516 101 139
FCTE 40-200/40/P 40 40 348 220 50 190 97 197 360 695 440 516 101 139
FCTE 40-200/55/P 40 40 348 220 50 190 97 214 360 695 440 550 101 141
FCTE 40-250/75/P 40 40 348 220 50 190 97 256 360 695 440 564 101 177
FCTE 40-250/110/P 40 40 348 220 50 190 97 256 360 695 440 602 101 179
FCTE 50-125/11/D 50 50 250 180 55 130 92 155 260 500 340 457 91 57
FCTE 50-125/15/D 50 50 250 180 55 130 92 155 260 500 340 457 91 63
FCTE 50-160/22/C 50 50 250 180 55 130 92 174 260 500 340 492 91 82
FCTE 50-160/30/P 50 50 250 180 55 130 92 174 260 500 340 491 91 85
FCTE 50-160/40/P 50 50 250 180 55 130 92 197 260 500 340 512 91 91
FCTE 50-200/55/P 50 50 348 230 60 185 125 214 360 695 440 578 110 108
FCTE 50-200/75/P 50 50 348 230 60 185 125 256 360 695 440 592 110 140
FCTE 50-250/92/P 50 50 348 230 60 185 125 256 360 695 440 630 110 198
FCTE 50-250/110/P 50 50 348 230 60 185 125 256 360 695 440 630 110 210
FCTE 50-250/150/P 50 50 348 230 60 185 125 313 360 695 440 719 110 226
FCTE 65-125/22/C 65 65 297 185 55 125 108 174 310 593 340 509 96 108
FCTE 65-125/30/P 65 65 297 185 55 125 108 174 310 593 340 509 96 113
FCTE 65-125/40/P 65 65 297 185 55 125 108 197 310 593 340 530 96 121
FCTE 65-160/55/P 65 65 297 185 55 125 108 214 310 593 340 564 96 137
FCTE 65-160/75/P 65 65 297 185 55 125 108 256 310 593 340 578 96 171
FCTE 65-200/92/P 65 65 348 260 59 185 130 256 360 695 475 635 109 202
FCTE 65-200/110/P 65 65 348 260 59 185 130 256 360 695 475 635 109 216
FCTE 65-250/150/P 65 65 348 260 59 185 130 313 360 695 475 724 109 248
FCTE 65-250/185/P 65 65 348 260 59 185 130 313 360 695 475 724 109 252
FCTE 65-250/220/P 65 65 348 260 59 185 130 313 360 695 475 724 109 272
FCTE 80-125/30/P 80 80 304 210 70 110 141 174 320 607 400 548 106 127
FCTE 80-125/40/P 80 80 304 210 70 110 141 197 320 607 400 569 106 133
FCTE 80-125/55/P 80 80 304 210 70 110 141 214 320 607 400 603 106 137
FCTE 80-160/75/P 80 80 304 210 70 110 141 256 320 607 400 617 106 169
FCTE 80-200/110/P 80 80 368 280 80 140 157 256 380 722 500 662 112 231
FCTE 80-200/150/P 80 80 368 280 80 140 157 313 380 722 500 751 112 251
FCTE 80-200/185/P 80 80 368 280 80 140 157 313 380 722 500 751 112 271
FCTE 80-200/220/P 80 80 368 280 80 140 157 313 380 722 500 751 112 295
FCTE 100-160/110/P 100 100 340 270 72 150 175 256 360 670 500 681 118 252
FCTE 100-200/185/P 100 100 408 310 80 150 180 313 410 798 550 774 128 363
FCTE 100-200/220/P 100 100 408 310 80 150 180 313 410 798 550 774 128 387
