DIMENSIONI E PESI SERIE FCE 2 poli 50 Hz
PUMP TYPE WEIGHT
BHL k
DNA DNM a e h1 h2 x b1 p max kg
FCE 40-125/07/D 40 40 70 70 160 160 129 116 155 243 320 448 86 29
FCE 40-125/11/D 40 40 70 70 160 160 129 116 155 243 320 448 86 30
FCE 40-160/15/D 40 40 70 70 160 160 129 116 155 243 320 448 86 31
FCE 40-160/22/C 40 40 70 70 160 160 134 116 174 248 320 483 86 35
FCE 40-200/40A/P 40 40 95 65 220 220 154 163 197 325 440 514 98 72
FCE 40-200/40/P 40 40 95 65 220 220 154 163 197 325 440 514 98 72
FCE 40-200/55/P 40 40 95 65 220 220 168 163 214 330 440 548 98 73
FCE 40-250/75/P 40 40 95 65 220 220 191 163 256 353 440 562 98 91
FCE 40-250/110/P 40 40 95 65 220 220 191 163 256 353 440 600 98 92
FCE 50-125/11/D 50 50 69 73 170 170 129 122 155 243 340 457 88 32
FCE 50-125/15/D 50 50 69 73 170 170 129 122 155 243 340 457 88 34
FCE 50-160/22/C 50 50 69 73 170 170 134 122 174 248 340 492 88 44
FCE 50-160/30/P 50 50 69 73 170 170 134 122 174 248 340 492 88 46
FCE 50-160/40/P 50 50 69 73 170 170 154 122 197 268 340 513 88 49
FCE 50-200/55/P 50 50 110 73 220 220 168 163 214 331 440 577 100 56
FCE 50-200/75/P 50 50 110 73 220 220 191 163 256 354 440 591 100 72
FCE 50-250/92/P 50 50 110 73 220 220 191 163 256 354 440 629 100 101
FCE 50-250/110/P 50 50 110 73 220 220 191 163 256 354 440 629 100 107
FCE 50-250/150/P 50 50 110 73 220 220 240 163 313 403 440 718 100 115
FCE 65-125/22/C 65 65 77 83 170 170 134 137 174 274 340 511 92 54
FCE 65-125/30/P 65 65 77 83 170 170 134 137 174 274 340 511 92 57
FCE 65-125/40/P 65 65 77 83 170 170 154 137 197 291 340 532 92 61
FCE 65-160/55/P 65 65 77 83 170 170 168 137 214 305 340 566 92 69
FCE 65-160/75/P 65 65 77 83 170 170 191 137 256 328 340 580 92 86
FCE 65-200/92/P 65 65 119 83 237,5 237,5 191 172 256 354 475 634 104 105
FCE 65-200/110/P 65 65 119 83 237,5 237,5 191 172 256 354 475 634 104 112
FCE 65-250/150/P 65 65 119 83 237,5 237,5 240 172 313 403 475 723 104 128
FCE 65-250/185/P 65 65 119 83 237,5 237,5 240 172 313 403 475 723 104 138
FCE 65-250/220/P 65 65 119 83 237,5 237,5 240 172 313 403 475 723 104 150
FCE 80-125/30/P 80 80 90 90 175 185 134 148 174 287 360 545 102 64
FCE 80-125/40/P 80 80 90 90 175 185 154 148 197 293 360 566 102 67
FCE 80-125/55/P 80 80 90 90 175 185 168 148 214 307 360 600 102 69
FCE 80-160/75/P 80 80 90 90 175 185 191 148 256 330 360 614 102 85
FCE 80-200/110/P 80 80 130 90 250 250 191 184 256 354 500 661 112 120
FCE 80-200/150/P 80 80 130 90 250 250 240 184 313 403 500 750 112 130
FCE 80-200/185/P 80 80 130 90 250 250 240 184 313 403 500 750 112 140
FCE 80-200/220/P 80 80 130 90 250 250 240 184 313 403 500 750 112 152
FCE 100-160/110/P 100 100 105 105 225 225 191 172 256 330 450 677 117 127
FCE 100-200/185/P 100 100 140 105 275 275 240 196 313 406 550 771 129 180
FCE 100-200/220/P 100 100 140 105 275 275 240 196 313 406 550 771 129 192
