Changing the vacuum hose
• Remove the clip [11-1] using a screwdriver,
for example.
• Pull off the vacuum hose.
• Slide the clip accompanying the new hose
over the hose.
• Slide the new hose all the way onto the
nipple.
• Make sure that the distance between the end
of the hose and the hose clip is 5 mm.
• Turn the screw [11-2] on the clip fi rmly to
secure the hose to the nipple.
Cleaning the button valve
The button valve needs to be removed prior
to cleaning.
• Use an Allen key (10) to press the button
valve [12-1] downwards.
• Turn the Allen key anticlockwise until the
insert [12-2] comes loose.
• Remove the unit consisting of the button
valve, spring and insert [12-3].
• Clean the seals.
• Screw the button valve back in.
9 Disposal
Do not throw the power tool in your house-
hold waste! Dispose of the machine, acces-
sories and packaging at an environmental-
ly-responsible recycling centre! Observe the
valid national regulations.
EU only: European Directive 2002/96/EC sti-
pulate that used electric power tools must be
collected separately and disposed of at an en-
vironmentally responsible recycling centre.
10 Accessories
Use only original Festool accessories and
Festool consumable material intended for
this machine because these components are
designed specifi cally for the machine. Using
accessories and consumable material from
other suppliers will most likely affect the
quality of your working results and limit any
warranty claims. Machine wear or your own
personal workload may increase depending
on the application. Protect yourself and your
machine, and preserve your warranty claims
by always using original Festool accessories
and Festool consumable material! The order
numbers of the accessories and tools can
be found in the Festool catalogue or on the
Internet under "www.festool.com".
11 Warranty
For our tools, we give warranty for material
and production defects in accordance with
the locally applicable legal provisions, but in
any case for at least 12 months. Within the
EU member states, the warranty period is
24 months (verifi cation through invoice or
delivery note).
Damage caused by the operator, natural
wear, overloading, incorrect handling or
through the use of the equipment not spe-
cifi ed in the operating manual, or damage
which was known at the time of purchase, is
not covered by the warranty. Furthermore,
damage caused by the use of non-original
Festool accessories and consumable ma-
terial (e.g. sanding pads) is also excluded.
Complaints can only be recognised if the
tool is returned while still assembled to the
supplier or an authorised Festool Customer
Service workshop. Keep the operating ma-
nual, safety instructions, spare parts list and
purchase receipt in a safe place. Otherwise
the respective, current warranty conditions
of the manufacturer shall apply.
Note
Due to continuous research and develop-
ment work, we reserve the right to make
changes to the technical content of this
documentation.
12 Declaration of Conformity
We declare under sole responsibility that this
product complies with the following norms
or normative documents:
EN 60204, EN 1012, EN 12100, EN
61000 in accordance with the regulati-
ons stipulated in Directive 98/37/EC (until
28.12.2009), 2006/42/EC (from 29.12.2009),
2004/08/EC.
11/2007
Dr. Johannes Steimel
Head of research and development
Festool GmbH, Wendlingen, Germany
