CAMERA INSTALLATION
NBLC-4204Z-SD network speed dome is usually
ceiling-mounted, and can be installed on the ceil-
ing or wall.
Note: There are two cable routes possible for ceil-
ing mount installation. Do not drill a hole in the
ceiling, and route cable from the side of the speed
dome. Drill a hole in the ceiling, and conceal cable
in the ceiling.
Install the default pedestal seal ring on the
pedestal as shown in top figure on previous
page.
Confirm installation position and cable route
first, drill holes on the ceiling according to the
installation position template, and then put
the three plastic expansion bolts into the
holes you just drilled.
Unscrew three locking screws on the enclo-
sure by using inner hex wrench, and remove
the enclosure.
Lay the outgoing cable according to the cable
route, and use three self-tapping screws to fix
the pedestal onto the installation surface,
then insert the screws into the expansion
bolts.
Use three locking screws to fix the dome en-
closure on the pedestal.
Now the camera installation is complete, and you
can adjust the lens angle, zoom, focus, etc. on the
WEB interface.
Using Ivideon
If you do not yet have an Ivideon account,
register on the website www.ivideon.com by
clicking “Create an account.”
Select the account type
For the home
For business
ATTENTION! Service plans for the home and for
business are different. You can find out more at:
https://www.ivideon.com/plans-for-business/
https://www.ivideon.com/plans-for-home/
Go to your Ivideon account by clicking “Sign
in” on the website www.ivideon.com.
Click “Add camera.”
Select “Add an Ivideon-powered camera” and
follow the instructions given.
1
2
3
4
5
Using the cloud archive
The cloud archive means storing video recordings
on Ivideon servers.
Recordings are made in a continuous cycle. The
duration of their storage depends on the selected
service plan.
Recordings are made only when the motion and
sound sensors are triggered.
Cloud archive recording requires a connection to
the Internet.
Access to the video archive is possible even if the
camera is lost or stolen.
You can also use a local archive.
A video archive recording goes to a selected
folder on the computer where the Ivideon Server
is installed, or to the camera’s SD card.
18 19
NBLC-4204Z-SD
Ready! You have successfully connected the
camera to your account in the Ivideon cloud. Now
you can access the features of video surveillance
through the Internet.
