SENA SRL [9/56] Getting started

SRL

English

6. Reattach the internal paddings beginning with the rear and click

the snap fasteners.

7. Lower the face cover completely.

4 GETTING STARTED

4.1 Button Operation

(+) Button

•Increase volume

•Track forward

•Scan radio stations

•Speed dial

Center Button

•Answer/End phone call

•Reject an incoming phone call

•Start/End intercom conversation

•Play/Pause music

•Enter voice configuration settings

(-) Button

•Decrease volume

•Track back

•FM Radio on/off
