SMH5 MultiCom
10
• Mono Speaker
• USB Power and Data Cable
• Microphone Sponges
• Hook and Loop Fastener for Speaker
• Speaker Pad
• Microphone Port Cap
3 INSTALLING THE SMH5 MULTICOM ON
YOUR HELMET
3.1 Installing the Main Unit
3.1.1 Using the Clamp Unit
1. Insert the clamp kit between the internal padding and external shell
on the left side of the helmet.
