SMH5 MultiCom
12
3. Plug the helmet speaker into the speaker cable connector.
3.3 Using the Static Boom Microphone
1. Make sure that the microphone’s receiver is located near your mouth.
2. Adjust the head of the microphone so that the tab is facing away from
your mouth.
2. Attach the speaker to the hook and loop fastener for the speaker
inside of the helmet.
Note:
If the helmet has deep ear pockets, you can use the speaker pad to place the
speaker closer to your ear.
Tab
