Lowara LSN 2 - 100-65-315 [7/12] Standard design with improved reliability
![Lowara LSN 2 - 50-32-315 [7/12] Standard design with improved reliability](/views2/1622027/page7/bg7.png)
Standard design with improved reliability
l Large capacity oil sump reduces oil tempera-
ture for extended bearing life.
l Heavy duty cast iron frame gives rigid support
to shaft and bearings for longer service.
l Magnetic drain plug maintains a clean oil
environment for extended bearing life.
l Standard double lip seals at pump and coup-
ling end maintain a tight, clean operating
environment.
Bearing Frame
l Rigid shaft desig for less than 0.05mm shaft
deflection.
l Heavy duty ball bearings engineered to provi-
de L10 bearing life in excess of 25,000 hours.
l Standard stainless steel shaft (1.4021) provi-
des reliable power transmission and corrosion
resistance at both the pump and coupling
ends.
Heavy Duty Shaft and Bearings
l Provides safe and accurate alignment of the
liquid end to the bearing frame.
l Large adapter windows make installation and
maintenance of seal and auxiliary support
systems trouble-free.
Ductile Iron Lantern / Frame Adapter
