Lowara LSN 2 - 100-65-315 [8/12] Part and material list
![Lowara LSN 2 - 125-100-250 [8/12] Part and material list](/views2/1622027/page8/bg8.png)
Part and Material list
Item Number Part Name Ductile Iron (NL) 316SS (VV) Duplex (WW)
102 V Casing Ductile Iron 316SS Duplex SS
161 Seal Chamber / Stuffing Box Cover Ductile Iron 316SS Duplex SS
183 Support Foot Carbon Steel
210 Shaft Stainless Steel (1.4021)
230 Impeller Cast Iron 316SS Duplex SS
320.51 Radial Bearing Single Row, Ball Bearing
320.52 Thrust Bearing Double Row Angular Contact Ball Bearing
330 Bearing Bracket Cast Iron
344 Lantern Ductile Iron
400 Case Gasket Non-Asbestos Aramid Fiber
412.21 O-Ring for Shaft Sleeve & Impeller Nut Teflon
412.41 O-Ring for Bearing Bracket Viton
421.41 Oil Seal, Inboard Lip Seal (Buna & Steel)
421.51 Oil Seal, Outboard Lip Seal (Buna & Steel)
507 Flinger Noryl 66
524 Shaft Sleeve Duplex SS (1.4462)
637 Oil Filler Plug Steel
901.11 Casing Bolts, Hex Cap Screw Stainless Steel (A2)
903.51 Drain Plug Steel Magnetic Tipped
912.11 Case Drain Plug 316SS
922 Impeller Nut Duplex SS
923.51 Bearing Lock Nut Steel/Nylon
932.51 Snap Ring / Circlip Carbon Steel
940.31 Impeller Key
Carbon Steel
Other Parts Not Shown
236 Inducer (optional) Duplex SS (1.4462)
452 Packing Gland 316SS
458 Lantern Ring glass fibre PTFE
461 Packing PTFE Impregnated
502.11 Wear Ring (optional) 1.4462
642 Oil Level Sight Glass Glass/Plastic
