Sound-pressure level/sound-power level

OF 1010 EBQ, OF 1010 EQ 79/90 dB(A)

OF 1010 Q 87/98 dB(A)

Measuring uncertainty allowance K = 3 dB

Wear ear protection!

Overall vibration levels (vector sum for three di-

rections) measured in accordance with EN 60745:

Vibration emission level (3-axis) a

= 5,5 m/s

Front handle a

= 8,0 m/s

Uncertainty K = 2,0 m/s²

The speciﬁ ed emissions values (vibration, noise)

– are used to compare machines.

– They are also used for making preliminary

estimates regarding vibration and noise loads

during operation.

– They represent the primary applications of the

power tool.

Increase possible for other applications, with

other insertion tools or if not maintained adequat-

ely. Take note of idling and downtimes of machine!

4 Power supply and start-up

The mains voltage must correspond to

the speciﬁ cation on the rating plate.

Switch (1.2) serves as an On/Off switch (I = On/0

= Off). It may be latched with the locking knob on

the side (1.1) for continuous operation. Pressing

the switch again releases the lock. See Fig. 1A for

connection and disconnection of the power cable.

5 Machine settings

Always remove the power supply plug from the

socket before carrying out any work on the ma-

chine.

5.1 Electronics

(OF 1010 EBQ/OF 1010 EQ)

Do not operate the tool if the electronics are faulty

as this can lead to the tool operating at excessive

speeds. If the start-up is not smooth or speed

adjustment is not possible, this indicates that the

electronics are faulty.

The OF 1010 EBQ, OF 1010 EQ features

full-wave electronics with the following

properties:

Smooth start-up

The smooth start-up ensures the router starts

up jolt-free.

Speed adjustment

You can regulate the speed steplessly between

10000 and 24000 min

-1

(OF 1010 EQ: 9500 - 23000

min

-1

) using the adjusting wheel (1.16). This ena-

bles you to optimise the cutting speed to suit the

material:

Material

Cutterdiameter

[mm]

Recom-

mended

cutter

material

3 - 14 15 - 25 16 - 35

Rotary control setting

Hardwood 6 - 4 5 - 3 3 - 1 HW (HSS)

Softwood 6 - 5 6 - 3 4 - 1 HSS (HW)

Laminated

chipboard

6 - 5 6 - 3 4 - 2 HW

Plastic 6 - 4 5 - 3 2 - 1 HW

Aluminium 3 - 1 2 - 1 1 HSS (HW)

Plaster-

board

2 - 1 1 1 HW

Constant speed

The pre-selected speed remains constant whether

the machine is in operation or in neutral position.

Temperature control

To prevent overheating, the safety electronics

switches the machine off when it reaches a critical

motor temperature. Let the machine cool down

for approx. 3-5 minutes before using it again. The

machine requires less time to cool down if it is

running, i.e. in neutral position.

Brake (OF 1010 EBQ)

The OF 1010 EBQ has an electronic brake which

brings the spindle with tool to a standstill within

approx. 2 seconds of the tool being switched off.

5.2 Changing tools

You can turn the machine upside down when

changing the tool.

a) Inserting the tool

- Insert the router into the open clamping collet

as far as possible, but at least up to the mark (

) on the router shank.

- Turn the spindle until the spindle stop (1.14)

catches when pressed and the spindle is locked

in place.

- Tighten the locking nut (1.13) with a 19 mm

open-end spanner.

b) Removing the tool

- Turn the spindle until the spindle stop (1.14)

catches when pressed and the spindle is locked

in place.

- Loosen the locking nut (1.13) using a 19 mm
