open-ended spanner until a resistance is felt.

Overcome this resistance by turning the open-

ended spanner even further.

- Remove the cutter.

5.3 How to change the clamping collet

Clamping collets are available for following shank

diameters: 6.0 mm, 6.35 mm, 8 mm (order num-

bers see Festool catalogue or Internet „www.

festool.com“.

- Fully unscrew the nut (1.13) and remove from

spindle together with the clamping collet.

- Only insert a new clamping collet in the spindle

when the nut is attached and engaged, then

tighten the nut slightly. Do not tighten the nut

until a milling cutter has been ﬁ tted.

5.4 Adjusting the milling depth

The milling depth is adjusted in three stages:

a) Setting the zero point

- Open the clamping lever (1.6) so that the stop

cylinder (1.7) can move freely.

- Place the router with router table (1.11) onto a

smooth surface. Open the rotary knob (1.15) and

press the machine down until the milling cutter

rests on the base.

- Clamp the machine in this position by tightening

the rotary knob (1.15).

- Press the stop cylinder against one of the three

sensing stops of the pivoted turret stop (1.9).

The individual height of each sensing stop can be

adjusted with a screwdriver:

Sensing stop min. height/max. height

A 38 mm/44 mm

B 44 mm/54 mm

C 54 mm/67 mm

- Push the pointer (1.4) down so that it shows 0

mm on the scale (1.5).

b) Setting the milling depth

The desired milling depth can be set either with

the quick depth adjustment or with the ﬁ ne depth

adjustment.

• Quick depth adjustment: Pull the stop cylinder

(1.7) up until the pointer shows the desired

milling depth. Clamp the stop cylinder in this

position with the clamping lever (1.6).

• Fine depth adjustment: Clamp the stop cyl-

inder with the clamping lever (1.6). Set the

desired milling depth by turning the adjusting

wheel (1.3) in. Turn the adjusting wheel to the

next mark on the scale to adjust the milling

depth by 0.1 mm. One full turn adjusts the

milling depth by 1 mm. The maximum adjust-

ment range with the adjusting wheel is 8 mm.

c) Increasing the milling depth

- Open the rotary knob (1.15) and press the tool

down until the stop cylinder touches the sensing

stops.

- Clamp the machine in this position by tightening

the rotary knob (1.15).

5.5 Dust extraction

Always connect the machine to a dust

extractor. A connection for extracting dust

and chips (1.8) is a standard feature on

the routers.

At the same time a chip guard (2.2) on the side

stop prevents ﬂ ying chips.

With edge routing, the best extraction effect is

obtained with the extractor hood AH-OF, available

as an accessory.

KSF-OF chip catcher

Using the KSF-OF chip catcher (9.1) (sometimes

included in the scope of delivery), the efﬁ ciency

of the extraction can be increased when routing

edges. Installation is similar to that of the copy-

ing ring.

The hood can be cut off along the grooves (9.2)

using a hacksaw and can thus be reduced in size.

The chip catcher can then be used for interior

radiuses up to a minimum radius of 40 mm.

6 Working with the machine

Always secure the workpiece in such a

manner that it cannot move while being

sawed.

The machine must always be held with

both hands by the designated handles

(1.15, 1.17).

You should wear a dust mask for work

which produces dust.

Always advance the router in the direction op-

posite to the direction of rotation of the cutter

(counter-routing)!

When routing (ensure feed direction of power tool

is the same as cutting direction of tool, Fig. 5).

6.1 Aluminium processing

When processing aluminium, the follow-

ing measures must be taken for safety

reasons:

- Pre-connect a residual current circuit-breaker

(FI, PRCD).
