- Connect the machine to a suitable dust extractor.

- Clean tool regularly of dust accumulations in

the motor housing.

Wear protective goggles.

6.2 Freehand routing

Freehand routing is the method normally used for

lettering or shapes, and for routing edges using

cutters with a guide pin or ring.

6.3 Routing with the parallel guide

The parallel guide (3.2) supplied can be used for

routing parallel to the edge of the workpiece (not

supplied with „Module 5A):

- Secure both guide rods (3.7) with the two rotary

knobs (3.3) on the side stop.

- Insert the guide rods into the grooves (1.10) on

the router base to the required distance and

secure them by turning the rotary knob (3.1).

This distance can be adjusted faster and more

precisely with the ﬁ ne precision adjustment (3.6),

available as an accessory:

- Turn the adjusting screw (3.4) in the plastic part

of the guide,

- clamp the guide rods with the rotating knobs

(3.5) in the precision adjustment,

- loosen the rotating knobs (3.3) of the parallel

guide,

- set the desired distance with the adjusting screw

and retighten the rotating knobs.

6.4 Routing with the TV-OF extension table

The extension table TV-OF, available as an acces-

sory, can be used to enlarge the support area of

the router and thus improve guidance, e.g. when

routing close to edges.

The extension table is ﬁ tted in the same way as

the parallel guide.

6.5 Routing with the FS guide system

The guide system, available as an accessory, fa-

cilitates routing straight grooves.

- Fasten the guide stop (4.1) to the platen with the

guide rails (3.7) of the parallel guide.

- Fasten the guide rail (4.3) with FSZ screw clamps

(4.4) to the workpiece. Make sure that the safety

distance X (Fig. 4) of 5 mm between the front

edge of the guide rail and cutter or groove is

observed.

- Place the guide stop onto the guide rail as shown

in Fig. 4. To ensure a backlash-free guidance of

the router stop you can adjust two guide cheeks

with a screwdriver through the side openings

(4.2).

- Screw the height-adjustable support (4.6) of the

router table’s threaded bore (6.6) in such a way

that the underside of the router table is parallel

to the surface of the workpiece.

When working with marking-up lines, the marks

on the platen (4.5) and the scale on the support

(4.6) show the centre axis of the cutter.

6.6 Routing with the SZ-OF 1000 beam com-

passes

With the SZ-OF 1000 beam compasses, which are

available as an accessory, you can make circular

cuts or segments of circles with diameters from

153 to 760 mm.

- The beam compasses are pushed into the front

groove of the platen until the desired radius is

set.

- Lock the beam compasses with the rotating

knob (1.12).

Practical hint

To prevent the tip of the compasses from making a

hole in the workpiece, ﬁ x a thin board at the centre

point by means of double-sided adhesive tape.

6.7 Copy cutting

A copying ring or the copying device is used to

exactly reproduce existing workpieces (both avail-

able as accessories).

a) Copying ring

Fasten the copying rings to the platen instead of

the cover ring (2.1) from below.

When choosing the size of the copying ring (5.1)

make sure that the cutter used (5.2) ﬁ ts through

the ring’s opening.

The distance Y (Fig. 5) between the workpiece and

template is calculated by

Y = (Ø copying ring - Ø cutter)

The copying ring can be centred exactly with the

centring cone ZF-OF (Order No. 486035).

b) Copying device

The angle arm WA-OF (6.5) and copier scanning

set KT-OF, consisting of roller holder (6.2) and

three copying rollers (6.1), are required for the

copying device.

- Screw the angle arm at the desired height in the

platen’s threaded bore (6.6) with the rotating

knob (6.4).

- Fit a copying roller in the roller holder and bolt

this to the angle arm with the rotating knob (6.3).

Make sure that the copying roller and cutter have

the same diameter!
