Bosch GLM 20 (0601072E00) [11/87] Hold function see figure b

The rear edge of the measuring tool ( ) is the reference level for the meas-

urement.

In order to carry out a measurement of the distance between two walls, for

example, place the measuring tool with the rear edge touching the first wall.

u Do not direct the laser beam at persons or animals and do not stare

into the laser beam yourself (even from a distance).

"Hold" Function (see figure B)

Press the on/off button (1) to stop the measuring process.

The laser beam is switched off and the Hold indicator ap-

pears on the display. The current measured value will con-

tinue to be shown in the bottom line of the display, but it

will no longer be continuously updated.

Press the on/off button (1) again to switch the laser back

on. The laser symbol flashes on the display. The pre-

vious measured value is displayed in the top line. The con-

tinuously updated/current measured value will be shown in

the bottom line.

Press the on/off button (1) again to stop the measuring pro-

cess again. The laser beam is switched off and the Hold in-

dicator appears on the display. The previous measured

value is displayed in the top line. The current measured

value will be shown in the bottom line, but it will no longer

be continuously updated.

If no button on the measuring tool is pressed for approx. 5 mins, the measur-

ing tool will automatically switch itself off to preserve battery life.

If a measured value has been held using the "Hold" function, it will be re-

tained if the tool switches off automatically. Once the measuring tool has

been switched on again by pressing the on/off button (1), the previous

measured value (e) is shown in the top line of the display.

Changing the Unit of Measurement

Switch the measuring tool off.

English | 11

Bosch Power Tools 1 609 92A 4JT | (05.09.2018)
