9
ENGLISH
(Original instructions)
Purpose of design
This angle grinder is designed especially for grinding.
Do not use sandpaper discs and grinding wheels other than
those with depressed center.
Do not use the tool in wet conditions or environments in the
presence of flammable liquids or gases.
This heavy-duty angle grinder is a professional power tool.
Do not allow children to come in contact with this tool.
Inexperienced operators are required to use this tool under
supervision.
Electrical Equipment Safety
Only one voltage is applicable to this tool. Be sure
to check that the power suuply corresponds to the
voltage on the rating plate. Your STANLEY tool is
equipped with double insulation, hence, it does not require
to be earthed.
When the power cord is damaged, have it sent to a
STANLEY service center for replacement to specially
prepared cables.
Using Extension Cords
If an extension cord is required, please select a 3-phase
extension cord that has been inspected and matches the
input power (see Technical Data) of this tool. The minimum
conductor size is 1.5mm
2
, maximum length is 30 meters.
When using a cable reel, be sure to pull out all the cables.
Assembly and Adjustment
Warning: To minimize the danger of serious
personal injury, please switch off the tool
power and disconnect all plugs before adjusting or
removing/installing any accessory. Before reassembling
the tool, press and release the trigger switch to make sure
the tool is already switched off.
Attaching and Removing the Wheel Guard (Fig. B)
Warning To minimize the danger of serious
personal injury, please switch off the tool
power and disconnect all plugs before adjusting or
removing/installing any accessory. Before reassembling
the tool, press and release the trigger switch to make sure
the tool is already switched off.
Attaching the guard
1. Place the angle grinder on a work bench, groove facing
up.
2. Bring the flange of the guard (3) collar over the groove
(11) of the gear housing.
3. Turn the guard (4) counterclockwise by 150 degrees.
4. Make sure that the screws (20) are tightened.
Removing the guard
1. Loosen the screws (20) on the guard collar.
2. Pull up the guard (3).
Warning: Do not operate the tool when the safety
guard is not in place.
Fitting and removing a grinding (Fig. C1, C2, C3)
Warning: Do not use damaged grinding wheels.
1. Place the tool on a work bench, guard up.
2. Fit the inner flange (6) correctly onto the spindle (7)
(Fig. C1).
3. Place the disc (8) on the flange (6) (Fig.C2). When fitting
a disc with a raised center, make sure that the raised
centre (9) is facing the flange (6).
4. Screw the out flange (10) onto the spindle (7) (Fig. C3)
- the ring on the flange (10) must fae towoards the disc
when fitting a grinding disc (A)
- the ring on the flange (10) must face away from the
disc when fitting a cutting disc (B)
5. Press the spindle lock (2) and rotate the spindle (7) until
it locks in position (Fig. C2).
6. Tighten the flange (10) with the two-pin spanner
supplied.
7. Release the spindle lock.
8. To remove the disc, loosen the flange (10) with the
two-pin spanner.
Warning: Do not use a damaged disc.
