5
ENGLISH
Explanation of general view
1-1. Hole diameter 8 mm (5/16")
2-1. 6 mm (1/4") Std. washer
2-2. No.10 wood screw 40 mm (1-1/2")
min. length
3-1. 6 mm (1/4") Std. washer
3-2. 6 mm (1/4") Mounting bolt & Nut
tighten securely
4-1. Push stick
5-1. Rip fence (Guide rule)
5-2. Miter gauge
6-1. Handle
7-1. Arrow pointer
7-2. Lock lever
8-1. 90 ﾟ adjusting screw
8-2. 45 ﾟ adjusting screw
10-1. Arrow pointer
11-1. Switch
11-2. Restart button
12-1. Screws
13-1. Sub table (R)
14-1. Screws
14-2. Sub table (back)
15-1. Slide table
15-2. Locking plate
16-1. Wrench
16-2. Wrench
16-3. Hex nut
17-1. Inner flange
17-2. Ring
17-3. Saw blade
17-4. Outer flange
17-5. Hex nut
18-1. Wrench
18-2. Wrench
19-1. Blade guard
19-2. Riving knife
19-3. Blade guard mounting portion
(stay)
20-1. Blade guard
20-2. Riving knife
21-1. Blade guard
21-2. Riving knife
22-1. Blade guard
22-2. Riving knife
23-1. Blade
23-2. These two clearances should be
equal.
23-3. Blade guard mounting portion
(stay)
23-4. Riving knife
23-5. Hex bolts (A)
23-6. Hex bolts (B)
24-1. Blade guard
24-2. Riving knife
25-1. Lever
26-1. Scale
27-1. Hex bolts
29-1. Guideline
29-2. Screw
31-1. Face/edge parallel
31-2. Handle
31-3. Wood screw
31-4. Glue together
32-1. Face/edge parallel
35-1. Push stick
36-1. Auxiliary fence
37-1. Push block
37-2. Auxiliary fence
38-1. Cross cutting
38-2. Mitering
38-3. Bevel cutting
38-4. Compound mitering (angles)
39-1. Miter gauge
39-2. Knob
43-1. Brush holder cap
43-2. Screwdriver
SPECIFICATIONS
MLT100
Model
(for European countries)
(for other than European countries)
Arbor hole 30 mm 25 mm and 25.4 mm
Blade diameter 260 mm 255 mm
90° 93 mm 90.5 mm
Max. cutting capacities
45° 64 mm 63 mm
No load speed (min
-1
) 4,300
(685 mm - 835 mm) x (955 mm - 1,155 mm) (685 mm - 835 mm) x (955 mm - 1,155 mm)
Table size (L x W)
with sub tables (R) and (back) with sub tables (R) and (back)
726 mm x 984 mm x 333 mm 726 mm x 984 mm x 333 mm
Dimensions (L x W x H) with table(s) not extended
with sub tables (R) and (back) with sub tables (R) and (back)
Net weight 35kg 35 kg
Safety class ./II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Note: Specifications may differ from country to country.
END215-3
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ DOUBLE INSULATION
･ Wear safety glasses.
･ Do not place hand or fingers close to
the blade.
･ Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of European Directive
2002/96/EC on waste electric and
