8 ENGLISH
Lighting up the front lamp
CAUTION: Do not look in the light or see the
source of light directly.
►Fig.5: 1. Lamp
Pulltheswitchtriggertolightupthelamp.Thelamp
keeps on lighting while the switch trigger is being pulled.
Thelampgoesoutapproximately10secondsafter
releasing the switch trigger.
NOTE:
Whenthetoolisoverheated,thetoolstops
automaticallyandthelampstartsashing.Inthiscase,
releasetheswitchtrigger.Thelampturnsoffin5minute.
NOTE:Useadryclothtowipethedirtoffthelensof
thelamp.Becarefulnottoscratchthelensoflamp,or
itmaylowertheillumination.
Reversing switch action
►Fig.6: 1. Reversing switch lever
CAUTION: Always check the direction of
rotation before operation.
CAUTION:
Use the reversing switch only after
the tool comes to a complete stop. Changing the direc-
tionofrotationbeforethetoolstopsmaydamagethetool.
CAUTION: When not operating the tool,
always set the reversing switch lever to the neu-
tral position.
Thistoolhasareversingswitchtochangethedirectionofrota-
tion. Depress the reversing switch lever from the A side for clock-
wise rotation or from the B side for counterclockwise rotation.
When the reversing switch lever is in the neutral posi-
tion,theswitchlevercannotbepulled.
Automatic speed change function
Thistoolhas"highspeedmode"and"hightorquemode".
Thetoolautomaticallychangestheoperationmode
dependingontheworkload.Whentheworkloadislow,
thetoolwillruninthe"highspeedmode"forquicker
operation.Whentheworkloadishigh,thetoolwillrun
inthe"hightorquemode"forpowerfuloperation.
►Fig.7: 1. Mode indicator
Themodeindicatorlightsupingreenwhenthetoolis
runningin"hightorquemode".
Ifthetoolisoperatedwithexcessiveload,themodeindicator
willblinkingreen.Themodeindicatorstopsblinkingand
thenlightsuporturnsoffifyoureducetheloadonthetool.
Mode indicator status Operation
mode
On Off Blinking
High speed
mode
Hightorque
mode
Overload
alert
Speed change
NOTICE: Use the speed change knob only after
the tool comes to a complete stop. Changing the
toolspeedbeforethetoolstopsmaydamagethetool.
NOTICE: Always set the speed change knob
carefully into the correct position.Ifyouoperate
the tool with the speed change knob positioned half-
waybetweentheposition1andtheposition2,the
toolmaybedamaged.
Twospeedrangescanbepreselectedwiththespeed
change knob.
Tochangethespeed,depressthelockbuttonandturn
the speed change knob so that the pointer points to the
position1forlowspeedortheposition2forhighspeed.
►Fig.8: 1. Lock button 2.Pointer3. Speed change
knob
Torque limiter
Thetorquelimiterwillactuatewhenacertaintorque
levelisreachedatthelowspeedsetting(position1).
Themotorwilldisengagefromtheoutputshaft.When
thishappens,thedrillbitwillstopturning.
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before carrying out any work on the tool.
Installing side grip (auxiliary handle)
CAUTION: Always be sure that the side grip is
installed securely before operation.
Screwthesidegriponthetoolsecurely.Thesidegrip
canbeinstalledoneithersideofthetool,whicheveris
convenient.
►Fig.9: 1. Side grip
Front handle
CAUTION: Do not x the front handle beyond
the limits of the arrow as illustrated. Be cautious
that your hand is not caught in the grip. Keep the
hand away from the drill chuck.Theycanleadto
serious accidents.
CAUTION: Always be sure that the hex bolts
(both sides) of the front handle are tightened
securely.
Thefronthandlecanbeinstalledinanypositionwithin
0°-112.5°asillustrated.
►Fig.10: 1. Front handle
Tochangetheposition,loosenthehexbolts(both
sides)withahexwrenchandturnthefronthandletothe
desiredposition.Thentightenthehexboltssecurely.
►Fig.11: 1. Front handle 2. Hex wrench
