NOTE:

• When the tool is overheated, the tool stops

automatically and the lamp starts flashing. In this

case, release the switch trigger. The lamp turns off

in one minute.

• Use a dry cloth to wipe the dirt off the lens of lamp.

Be careful not to scratch the lens of lamp, or it

may lower the illumination.

Reversing switch action

CAUTION:

• Always check the direction of rotation before

operation.

• Use the reversing switch only after the tool comes

to a complete stop. Changing the direction of

rotation before the tool stops may damage the tool.

• When not operating the tool, always set the

reversing switch lever to the neutral position.

Fig.6

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the

A side for clockwise rotation or from the B side for

counterclockwise rotation.

When the reversing switch lever is in the neutral

position, the switch trigger cannot be pulled.

Speed change

CAUTION:

• Always set the speed change lever fully to the

correct position. If you operate the tool with the

speed change lever positioned halfway between

the "1" side and, "2" side, the tool may be

damaged.

• Do not use the speed change lever while the tool

is running. The tool may be damaged.

Fig.7

To change the speed, first switch off the tool and then

slide the speed change lever to the "2" side for high

speed or, "1" side for low speed. Be sure that the speed

change lever is set to the correct position before

operation. Use the right speed for your job.

Selecting the action mode

CAUTION:

• Always set the ring correctly to your desired mode

mark. If you operate the tool with the ring

positioned halfway between the mode marks, the

tool may be damaged.

Fig.8

This tool has an action mode changing ring. For drilling,

turn the ring so that the arrow on the tool body points

toward the

mark on the ring. For screwing, turn the

ring so that the arrow points toward the

mark on the

ring.

Adjusting the fastening torque

(screwdriver mode "

Fig.9

The fastening torque can be adjusted in 21 steps by

turning the adjusting ring so that its graduations are

aligned with the pointer on the tool body.

First, slide the action mode change lever to the position

symbol.

The fastening torque is minimum when the number 1 is

aligned with the pointer, and maximum when the

marking is aligned with the pointer. The clutch will slip at

various torque levels when set at the number 1 to 21.

Before actual operation, drive a trial screw into your

material or a piece of duplicate material to determine

which torque level is required for a particular application.

NOTE:

•

The adjusting ring does not lock when the pointer is

positioned only halfway between the graduations.

ASSEMBLY

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before carrying out

any work on the tool.

Installing side grip (auxiliary handle)

Fig.10

Always use the side grip to ensure operating safety.

Insert the side grip so that the groove on the arm fit in

one of the counter parts on the tool. Then tighten the

grip by turning clockwise.

Depending the operations, you can install the side grip

either right or left side of the tool.

Installing or removing driver bit or drill bit

Fig.11

Turn the sleeve counterclockwise to open the chuck

jaws. Place the bit in the chuck as far as it will go. Turn

the sleeve clockwise to tighten the chuck. To remove

the bit, turn the sleeve counterclockwise.

Installing bit holder

Fig.12

Fit the bit holder into the protrusion at the tool foot on

either right or left side and secure it with a screw.

When not using the driver bit, keep it in the bit holders.

Bits 45 mm long can be kept there.

Hook

Fig.13

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool.

To install the hook, insert it into a groove in the tool

housing on either side and then secure it with a screw.

To remove, loosen the screw and then take it out.
