OPERATION

Fig.14

Screwdriving operation

First, slide the action mode change lever so that it

points to the

marking. Adjust the adjusting ring to the

proper torque level for your work. Then proceed as

follows.

Place the point of the driver bit in the screw head and

apply pressure to the tool. Start the tool slowly and then

increase the speed gradually. Release the switch trigger

as soon as the clutch cuts in.

NOTE:

• Make sure that the driver bit is inserted straight in

the screw head, or the screw and/or bit may be

damaged.

• When driving wood screw, predrill a pilot hole 2/3

the diameter of the screw. It makes driving easier

and prevents splitting of the workpiece.

• If the tool is operated continuously until the battery

cartridge has discharged, allow the tool to rest for

15 minutes before proceeding with a fresh battery.

Drilling operation

Drilling in wood

When drilling in wood, the best results are obtained with

wood drills equipped with a guide screw. The guide

screw makes drilling easier by pulling the bit into the

workpiece.

Drilling in metal

To prevent the bit from slipping when starting a hole,

make an indentation with a center-punch and hammer

at the point to be drilled. Place the point of the bit in the

indentation and start drilling.

Use a cutting lubricant when drilling metals. The

exceptions are iron and brass which should be drilled

dry.

First, slide the action mode change lever so that it

points to the

marking. The adjusting ring can be

aligned in any torque levels for this operation. Then

proceed as follows.

CAUTION:

• Pressing excessively on the tool will not speed up

the drilling. In fact, this excessive pressure will

only serve to damage the tip of your bit, decrease

the tool performance and shorten the service life

of the tool.

• There is a tremendous force exerted on the tool/bit

at the time of hole break through. Hold the tool

firmly and exert care when the bit begins to break

through the workpiece.

• A stuck bit can be removed simply by setting the

reversing switch to reverse rotation in order to

back out. However, the tool may back out abruptly

if you do not hold it firmly.

• Always secure small workpieces in a vise or

similar hold-down device.

• If the tool is operated continuously until the battery

cartridge has discharged, allow the tool to rest for

15 minutes before proceeding with a fresh battery.

MAINTENANCE

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before attempting to

perform inspection or maintenance.

• Never use gasoline, benzine, thinner, alcohol or

the like. Discoloration, deformation or cracks may

result.

To maintain product SAFETY and RELIABILITY, repairs,

any other maintenance or adjustment should be

performed by Makita Authorized Service Centers,

always using Makita replacement parts.

OPTIONAL ACCESSORIES

CAUTION:

• These accessories or attachments are

recommended for use with your Makita tool

specified in this manual. The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or

attachment for its stated purpose.

If you need any assistance for more details regarding

these accessories, ask your local Makita Service Center.

• Drill bits

• Screw bits

• Hook

• Grip assembly

• Makita genuine battery and charger

• Rubber pad assembly

• Wool bonnet

• Foam polishing pad

NOTE:

• Some items in the list may be included in the tool

package as standard accessories. They may differ

from country to country.
