User manual
CROSS LINE LASER
User manual
CROSS LINE LASEREN EN
CONDTROL UniX 360 Green Pro CONDTROL UniX 360 Green Pro
SPECIFICATIONS
Working range/with detector 50 m / 100 m*
Leveling accuracy ± 0,2 mm/m
Self-leveling range ±5°
Leveling duration, typically <3 s
Receiver mode √
inclined planes mode √
Operating temperature +5°С…+40°С
Storage temperature -30°С…+80°С
Relative air humidity, max 90%
Laser type 520 nm, <1mW
Laser class 2
Tripod mount 1/4''
Batteries 4x1,5V LR6 (AA)
Operating life time 3 h
Weight 620 g
Dimensions 140х104х125mm
* The operating range may differ from the declared depending on the lighting conditions.
ACCURACY CHECK
Checking of the horizontal line
Checking of the horizontal line
For this check, a free measuring distance of 5 meters on a firm surface between two walls A
and B is required.
1. Mount the instrument onto a tripod or place it on a firm and level surface close to wall A
(see figure I). Switch on the instrument. Select cross-line operation with automatic leveling
Direct the laser against the close wall A and allow the instrument to level in. Make A1 mark at
the centre of the point where the laser lines cross each other on the wall (point I).
Mark point B on the opposite wall.
2. Turn the instrument by 90°. Check whether the horizontal line is in level with point B1
within
±1 mm (see figure J). If deviation between the laser line and the B1 mark is greater than ±1
mm, apply to service centre.
3. Repeat step 2 for 2 more times, turning the instrument in one direction.
4. Without turning the instrument, position it close to wall B. Make B2 mark at the centre
of the point where the laser lines cross each other on the wall (B1 and B2 marks should be
placed on the same Vertical line) (see figure K)
5. Turn the instrument by 180° and direct it against the wall A, place A2 mark for the cross
point of the laser lines on the wall (see figure L). (B1 and B2 marks should be placed on the
same Vertical line).
6. Check the distance dA, dB between marked points A1, A2 and B1, B2 accordingly (see
figure L).
When the maximum deviation exceeds 2 mm, you should contact CONDTROL service centre.
Checking of the vertical line
Place the instrument at a distance of 1,5m from the instrument (see figure M).
Fix plumb bob on the wall, making sure that the bob can swing free.
Switch on the device and align the vertical laser to the plumb line.
Acceptable deviation between the laser line and the plumb line is not greater than ±0.2 mm per
1m of the plumb bob length (for the 2.5m plumb bob, acceptable deviation is 0.5mm).
