11 ENGLISH
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before carrying out any work on the tool.
Assembling hose
Insertthehosecuffintothevacuumcleanerbodyand
turn it clockwise.
►Fig.14: 1.Hosecuff2. Vacuum cleaner body
Assembling wand and nozzle
For vacuum cleaner type only
Connectthenozzletotheextensionwand.Afterthat,
shoulder the vacuum cleaner body then connect the
hose with the extension wand.
Connecting extension wand and nozzle
►Fig.15: 1.Extensionwand2. Free nozzle
3.T-shapenozzle
Connecting hose and extension wand
►Fig.16: 1. Hose 2.Extensionwand3. Free nozzle
NOTE:Thefreenozzlecanbeattachedtothehose
directly.
Connecting the tool
For dust extraction type only
Connectthefrontcuffonthehosewiththetool's
extraction outlet.
►Fig.17: 1.Frontcuff2.Extractionoutlet
Alwaysuseasuitablefrontcuff.Thefrontcuffcanbe
detached by turning it counterclockwise while holding
thehose.Whenconnecting,makesurethatthefront
cuffissecurelyscrewedinthehose.
►Fig.18: 1. Hose 2.Frontcuff
Whenusingthefrontcuff24,insertittothefrontcuff22
that is connected to the hose.
►Fig.19: 1.Frontcuff222.Frontcuff24
Installing lter bag
CAUTION: Do not use a damaged lter bag.
Always use the vacuum cleaner with the lter bag
properly installed. Otherwise the vacuumed dust
or particles may be exhausted from the cleaner
and they may cause respiratory disease to the
operator.
NOTICE:Whenthelterbagisalreadyfull,replace
withnewone.Continuoususewiththelterbagfull
results in reduced suction power.
1. Unlockthelatchbyliftingthebottomside.Push
thegroovedareatoliftthefrontlatchingside.Pullthe
latch to open the lid.
►Fig.20: 1. Hook 2. Lid
2. Insertthelterbagintotheslitontheuppersideof
the room as illustrated.
►Fig.21: 1. Slit 2. Filter bag / Dust bag
When using the dust bag (optional accessory), insert
thebrimofthedustbagintotheslit.
►Fig.22: 1. Slit 2. Brim
3. Aligntheholeofthelterbagwiththehosecuff
and push the cardboard portion to the end. Make sure
thattherubberringonthelterbaggoesovertherim
onthehosecuff.
►Fig.23: 1.Rubberringonthelterbag2. Rim on
thehosecuff3.Cardboardportionofthe
lterbag4.Hosecuff
OPERATION
WARNING: Operators shall be adequately
instructed on the use of the vacuum cleaner.
WARNING: This vacuum cleaner is not suit-
able for picking up hazardous dust.
CAUTION: This cleaner is for dry use only.
CAUTION: This cleaner is for indoor use only.
CAUTION: Always insert the battery cartridge
all the way until it locks in place.Ifyoucanseethe
redindicatorontheuppersideofthebutton,itisnot
lockedcompletely.Insertitfullyuntiltheredindicator
cannotbeseen.Ifnot,itmayaccidentallyfalloutof
thetool,causinginjurytoyouorsomeonearound
you.
1. Shoulderthevacuumcleanerbodyandfas-
tenupperandlowerbelts.Adjustthetightnessas
necessary.
►Fig.24
2. Press
buttontostartvacuuming.Ifyouwant
to lower the suction power, press button one more
time.Press button to stop.
►Fig.25
During the operation, hook the switch box on the lower
belt.Thehookcanbeslantedforlightingforward.
►Fig.26
NOTE:Thevacuumcleanerwillautomatically
switchesoffandtheLEDlightasheswhenthevac-
uumcleanerisoverheatedduetothereducedair-
owintothemachinecausedbycloggedhose,pipe,
lterorotherreasons.Inthiscase,removethecause
oftheproblemandcoolthevacuumcleanerbefore
restarting.
3. Replacethelterbagwhenitbecomesfull.Open
thelidandtakeoutthelterbag.Pullthestriponthe
sideoftheopeningtoshutthelterbaganddisposeof
thelterbaginwhole.
►Fig.27: 1. Strip
When using a dust bag (optional accessory), take out
thedustbaganddisposeofthedustbyreleasingthe
latch.
