Electronic function

Constant speed control

• Possible to get fine finish, because the rotating

speed is kept constantly even under the loaded

condition.

• Additionally, when the load on the tool exceeds

admissible levels, power to the motor is reduced to

protect the motor from overheating. When the load

returns to admissible levels, the tool will operate as

normal.

Soft start feature

• Soft start because of suppressed starting shock.

Indication lamp

008416

The indication lamp lights up green when the tool is

plugged. If the indication lamp does not light up, the

mains cord or the controller may be defective. The

indication lamp is lit but the tool does not start even if the

tool is switched on, the carbon brushes may be worn out,

or the controller, the motor or the ON/OFF switch may be

defective.

Unintentional restart proof

Even locking lever keeping the switch trigger depressed

(Lock-on position) does not allow the tool to restart even

when the tool is plugged.

At this time, the indication lamp flickers red and shows

the unintentional restart proof device is on function.

To cancel the unintentional restart proof, pull the switch

trigger fully, then release it.

Level planing (for PC5001C only)

009847

To level a surface, the base of the planer should be

aligned with the diamond wheel. The front roller should

be adjusted (use hex wrench) upward to the level

required for the desired stock removal amount.

To change the amount of stock (concrete) removed,

loosen the hex socket head bolts on the base holder with

the hex wrench. Raise or lower the front roller to adjust

the gap between it and the diamond wheel. The

difference is the stock removal amount. Then secure the

hex socket head bolts very carefully.

009848

NOTE:

• Maximum stock removal should be less than 4.0

mm.

Tilting base for smoother planing ( for

PC5001C only)

009849

For smooth removal of a given surface roughness or

texture, tilting the base is helpful. Use the hex wrench to

loosen the two hex socket head bolts securing the base

on either side.

Use a hex wrench to lower the three hex socket head

bolts on the base by turning them on the base clockwise.

009850

Use a square or ruler to obtain the desired base angle in

relation to the diamond wheel. Then secure carefully the

hex socket head bolts on either side of the base. Adjust

center of base near wheel so that it is on the same level

1. Hex wrench

2. Hex socket head

bolt

1. Base

2. Hex wrench

3. Hex socket head

bolt

1. Hex socket head

bolt

2. Stock removal

amount

1. Base (for

PC5001C only)

2. Hex wrench

3. Front roller

1. Indication lamp
