15 ENGLISH
For ELM4120:
Set the mowing height to "2".
►Fig.40: 1.Adjustinglever
4.
Loosen the thumb nuts while holding the handle, then
widen the handle outside a little, and then fold the handle.
►Fig.41: 1.Thumbnut2. Handle 3.Mark4. Arrow
CAUTION: When folding the handle, be care-
ful not to pinch your hand or ngers.
NOTE:Makesurethatthearrowindicatesthemark
at the most front position.
5. Tightenthethumbnuts.
►Fig.42: 1.Thumbnut
6. Placethemachineasshowninthegure.
►Fig.43
CAUTION: Be sure to store this machine
indoors and place it on a at surface. Otherwise,
themachinemayfallandcauseaninjury.
You can also store the machine by folding the handle.
CAUTION: Before opening the levers, hold
the upper handle rmly. Otherwise, the handle
may fall and cause an injury.
1. Opentheleverswhileholdingtheupperhandle.
►Fig.44: 1.Lever
2. Fold the upper handle.
►Fig.45: 1. Upper handle
Replacing the mower blade
CAUTION: Do not use any wrench other than
the standard hex wrench when replacing the
mower blade. Using a different wrench may lead to
over-tighteningorlooseness,whichmaycauseinjury.
1. Unplug the extension cord and stand up the
machine. (Refer to the instructions for storing.)
2. Insert the pin into the hole, and then hold the han-
dle with one hand and loosen the bolt with the wrench
counterclockwise.
►Fig.46: 1. Blade 2. Wrench 3. Pin
3. Removethemowerblade.
For ELM3320
Removethebolt,washer,mowerblade,andbracketin
order.
►Fig.47: 1. Bracket 2.Mowerblade3. Washer 4. Bolt
For ELM3720/ELM4120
Removethebolt,washer,mowerblade,bracket,and
spacer in order.
►Fig.48: 1. Spacer 2. Bracket 3.Mowerblade
4. Washer 5. Bolt
4. Attach a new mower blade, then insert the pin into
the hole, and then hold the handle with one hand and
tightentheboltwiththewrenchclockwisermly.
►Fig.49: 1.Mowerblade2. Wrench 3. Pin
Extension cord
You should only use extension cords for outdoor use,
PVC or rubber cord ordinary duty with a cross sectional
area not less than 1.5 mm
2
.
Before and during use, check the supply and extension
cords for damage. Do not use the appliance if the cord
is damaged or worn. Keep extension cord away from
cutting elements. If the cord is damaged during use,
disconnect the cord from the supply immediately. Do not
touch the cord before disconnecting the supply.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
If you need any assistance for more details regard-
ingtheseaccessories,askyourlocalMakitaService
Center.
• Mowerblade
NOTE: Some items in the list may be included in the
toolpackageasstandardaccessories.Theymay
differ from country to country.
