Gespasa IRON-50 Ex 230 VAC (10035) Инструкция по эксплуатации онлайн
Partida Horta d’Amunt s/n · Apdo. de Correos nº 149
25600 BALAGUER (Lleida) · SPAIN
++34 (9)73 451 072
++34 (9)73 448 400
gespasa@gespasa.es · http://www.gespasa.es
INSTRUCTION MANUAL
WARRANTY AND CONFORMITY DECLARATION
anti-clockwise
turn sense
sentido giro
antihorario
1
2
3
5
4
6
8
7
10
9
12
11
13
14
16
15
17
IRON-50 Ex 0.18 kW 230 VAC 50 Hz CODE 10035
No. DESCRIPTION CODE
1 M-4x12 mm DIN.912 SCREW 805400035
2 PUMP BODY COVER 003504000
3 58x3 mm VITON JOINT 803101062
4 5-BLADE SET 000002109
5 F-211 SINTERED ROLLER 000002210
6 4x4x10 mm SHAFT KEY 000002002
7 SEGER INT.30 RING 800303012
8 PUMP FILTER 003502001
9 BY-PASS VALVE 805606102
10 PUMP BODY S003503003
11 M-5x30 mm STUD 100301003
12 SEGER EXT-10 SAE 1070 RING 800303010
13 MECHANICAL CERAMIC SEAL 804601007
14 26x2 mm VITON JOINT 803101060
15 SEAL SUPPORT 100304004
16 EExd MOTOR 100301201
17 BYPASS SPRING 000002007
M-237
130
250
h: 150
Ø
7
90
108
112
165
Содержание
- Instruction manual warranty and conformity declaration 1
- Iron 50 ex 0 8 kw 230 vac 50 hz 1
- Installation 2
- Security instructions 2
- Technical specifications 2
- Warnings 2
- Correct pump use 3
- Maintenance 3
- Repair 3
- All the products manufactured by tot comercial sa have a warranty of 12 twelve months or 500 000 litres from their purchase against any manufacturing defect 2 tot comercial sa guarantees in the warranty period the change the devolution of the defective part or product this material must be sent with prepaid freight to our factory or any appointed technical service after our technical inspection it will be determined whether the responsibility is from the manufacturer the user the installer or the transport 3 the warranty does not cover the inadequate use the negligence the abuse the corrosion the manipulation or the wrong installation of the products the use of non original spare parts or not corresponding to the specifi c model all the manufactured and or commercialized equipment must be installed according to the manufacturer s instructions 4 the accessories and the products not manufactured by tot comercial sa are liable for their original manufacturer s warranty 5 because of the con 4
- Breakdown possible cause solution 4
- Eu conformity declaration 4
- Gespasa 4
- Ii 2 g ex h iib t4 gb 4
- Iron 50 ex 230 vac 4
- Problem guide 4
- Self suction explosionproof fuel pum 4
- Warranty 4
