battery charger apart in a dry,
indoor and locked area. Make
sure that children and persons
that are not approved cannot
get access to the product,
battery or battery charger.
Assembly
Introduction
WARNING: Before you assemble the
product, read the safety chapter.
WARNING: To prevent accidental start
during assembly, turn the safety key to 0,
remove the battery and wait at minimum 5
seconds.
To assemble the handle
1. Loosen the lower knobs.
2. Move the knobs to the lower end of the grooves on
the left and the right side of the product. (Fig. 25)
3. Set the handle height in one of the 2 available
positions.
4. Move the knobs up in the direction of the handle until
they stop and you hear a click. (Fig. 26)
5. Tighten the knobs fully.
To assemble the grass catcher
1. Attach the grass catcher frame to the grass bag with
the rigid part of the bag on the bottom. Keep the
handle of the frame on top of the grass bag. (Fig. 27)
2. Attach the bottom section of the grass catcher frame
in the groove on the bottom of the grass catcher.
3. Attach the grass bag to the grass catcher frame with
the clips. (Fig. 28)
4. Lift the rear cover.
5. Attach the grass catcher to the top edge of the
chassis.
6. Put the lower part of the grass catcher into the grass
discharge channel. (Fig. 29)
To assemble the mulch plug
(accessory)
1. Lift up the rear cover and remove the grass catcher.
2. Put the mulch plug into the discharge channel. (Fig.
30)
3. Replace the blade with the mulch blade that is
supplied in the mulch kit. Refer to
To remove and
replace the blade on page 19
.
Operation
Introduction
WARNING: Before you operate the product,
you must read and understand the safety
chapter.
Husqvarna Connect
The product has
Bluetooth
®
wireless technology and
can connect to mobile devices that have the Husqvarna
Connect app installed. Husqvarna Connect is a free app
for your mobile device. The Husqvarna Connect app
gives extended functions for your Husqvarna product.
To start to use Husqvarna Connect
1. Download the Husqvarna Connect app on your
mobile device.
2. Register in the Husqvarna Connect app.
3. Do the instruction steps in the Husqvarna Connect
app to connect and register the product.
Bluetooth
®
wireless technology
The symbol for
Bluetooth
®
wireless technology comes
on when your mobile device is connected to the product.
(Fig. 31)
To set the product in operation
position
1. Fold the handle to upright position. (Fig. 32)
2. Move the knobs up in the direction of the handle until
they stop and you hear a click. (Fig. 26)
3. Tighten the knobs fully.
To set the cutting height
The cutting height can be adjusted in 6 levels.
16 890 - 002 - 21.12.2018
