11
WX178 WX178.1 WX178.2 WX178.3 WX178.4 WX178.9
Lithium-Ion Cordless Drill/Driver
ACCESSORIES
WX178 WX178.1 WX178.2
Double ended bits
(PH2/SL5.5)
1 1 1
Battery pack
(WA3551.1)
1 2 1
Charger(WA3860) 1 1 1
Bit clip 1 1 1
Hook 1 1 1
Multi-purpose drill
bits*
/ / 3
Roll-up drill bits kit / / /
WX178.3 WX178.4 WX178.9
Double ended bits
(PH2/SL5.5)
1 1 1
Battery pack
(WA3551.1)
2 2 /
Charger(WA3860) 1 1 /
Bit clip 1 1 1
Hook 1 1 1
Multi-purpose drill
bits*
3 3 /
Roll-up drill bits kit / 30 /
*Innovative drill bits for steel, wood, masonry, uPVC,
ceramics and concrete multi-layered materials.
We recommend that you purchase your accessories
listed in the above list from the same store that sold
you the tool. Refer to the accessory packaging for
further details. Store personnel can assist you and
offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for driving in and
loosening fasteners as well as for drilling in wood,
metal and plastic.
ASSEMBLY AND
OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing the Battery Pack
See Fig. A1
Charging the Battery Pack See Fig. A2
Installing the Battery Pack See Fig. A3
ASSEMBLY
--Inserting the Bits See Fig. B1 B2
--Removing the Bits See Fig. B3
Assembling the belt hook and
bit clip
See Fig. C1,C2,
C3,C4
OPERATION
Bit Lock
TM
Adjustment
The Bit Lock
TM
switch (12) equipped in this tool can
release or grab a bit very quickly and automatically.
This can be realized by rotating the Bit Lock
TM
ring
clockwise or counterclockwise.
WARNING: Always ensure the bit is secure
before starting the tool. Damage to the Chuck
or a loose bit may cause possible personal injury.
NOTE: When the chuck jaws become fully opened
or closed, the clutch will activate, making a clicking
sound. This sound is normal.
If the Bit Lock
TM
Switch (12) does not operate, confirm
the battery is charged and depress the trigger briefly.
Keep drill tilted upward when adjusting the chuck to
prevent bit from falling out.
Forward/Reverse Rotation Switch
WARNING: Never change
the direction of rotation
when the Chuck is rotating. Wait
until it has stopped!
See Fig. D1,
D2, D3
Function Mode Selection
Press the function button to select operation mode.
The button will illuminate in blue for a few seconds.
Depress the Variable Speed Switch (10) slightly to
illuminate the function button again.
