ENGLISH
8
(Original instructions)
Features
This tool includes some or all of the
following features.
1. Variable speed switch
2. Forward/reverse slider
3. Torque adjustment collar
4. Keyless chuck
5. Dual range gearing
6. LED work light
7. Battery
8. Battery release button
Assembly
Use
Warning! Let the tool work at its own pace.
Do not overload.
Charging the battery (fig.A)
The battery needs to be charged before first
use and whenever it fails to produce
sucient power on jobs that were easily
done before. The battery may become
warm while charging; this is normal and
does not indicate a problem.
Warning! Do not charge the battery at
ambient temperatures below 10 °C or above
40 °C. Recommended charging
temperature: approx. 24 °C.
Note: The charger will not charge a battery
if the cell temperature is below
approximately 10 °C or above 40 °C.
The battery should be left in the charger
and the charger will begin to charge
automatically when the cell temperature
warms up or cools down.
• To charge the battery, insert the USB
charger (9) into the Battery (7).
• Plug the charger (9) into a suitable
power source and switch on.
• Charge discharged batteries within 1
week. Battery life willn be greatly
diminished if stored in a discharged
state.
Warning! fire Hazard. When disconnecting
the charger from the tool, be sure to unplug
the charger from the outlet first, then
disconnect the charger cord from the tool.
Fitting and removing the battery
(fig.B)
• To fit the battery, line it up with the
receptacle on the tool. Slot the battery
into the receptacle and push up until the
battery snaps into place.
• To remove the battery, push the release
buttons (8) while at the same time pulling
the battery out of the receptacle.
Operating Instructions
Trigger switch & reversing button
(fig.
E)
• The drill is turned ON and OFF by pulling
and releasing the trigger switch (1). The
farther the trigger is depressed, the
higher the speed of the drill.
• A forward/reverse control button (2)
determines the direction of the tool.
• To select forward rotation, release the
trigger switch and depress the
forward/reverse control button to the left.
• To select reverse, depress the
forward/reverse control button the
opposite direction.
Torque control (fig.C)
This tool is fitted with a torque adjustment
collar (3) to select the operating mode and
to set the torque for tightening screws.
Large screws and hard workpiece materials
require a higher torque setting than small
screws and soft workpiece materials.
• For drilling in wood, metal and plastics,
set the collar to the drilling position
symbol
• For screwdriving, set the collar to the
desired setting. If you do not yet know
the appropriate setting, proceed as
follows:
• Set the collar to the lowest torque setting.
• Tighten the first screw.
