9
ENGLISH
(Original instructions)
• If the clutch ratchets before the desired
result is achieved, increase the collar
setting and continue tightening the
screw. Repeat until you reach the correct
setting. Use this setting for the remaining
screws.
Keyless chuck (fig. D)
To insert a drill bit or other accessory:
• Grasp the rear half of the chuck (4a) with
one hand and use your other hand to
rotate the front half (4) in the
counterclockwise direction, as viewed
from the chuck end.
• Insert the bit or other accessory fully into
the chuck, and tighten securely by
holding the rear half of the chuck and
rotating the front portion in the
clockwise direction as viewed from the
chuck end.
Warning! Do not attempt to tighten drill bits
(or any other accessory) by gripping the
front part of the chuck and turning the tool
on. Damage to the chuck and personal
injury may occur when changing
accessories.
Dual range gearing (Figure F)
The dual range feature of your drill allows
you to shift gears for greater versatility. To
select low speed, high torque setting
(position 1), turn tool off and permit to stop.
Slide gear shifter button (5) away from the
chuck. To select the high speed, low torque
setting (position 2), turn tool off and permit
to stop. Slide gear shifter button towards
the chuck.
Note: Do not change gears when tool is
running. If you are having trouble changing
gears, make sure that the dual range gear
button is either completely pushed forward
or completely pushed back.
Drilling/screwdriving
• Select forward or reverse rotation using
the forward/reverse slider (2).
• To switch the tool on, press the switch
(1). The tool speed depends on how far
you press the switch.
• To switch the tool off, release the switch.
Hints for optimum use
Drilling
• Use sharp drill bits only.
• Support and secure work properly, as
instructed in the Safety Instructions.
• Use appropriate and required safety
equipment, as instructed in the Safety
Instructions.
• Secure and maintain work area, as
instructed in the Safety Instructions.
• Run the drill very slowly, using light
pressure, until the hole is started enough
to keep the drill bit from slipping out of it.
• Apply pressure in a straight line with the
bit. Use enough pressure to keep the bit
biting but not so much as to stall the
motor or deflect the bit.
• Hold the drill firmly with two hands to
control its twisting action.
• DO NOT CLICK THE TRIGGER OF A
STALLED DRILL OFF AND ON IN AN
ATTEMPT TO START IT. DAMAGE TO THE
DRILL CAN RESULT.
• Minimize stalling on breakthrough by
reducing pressure and slowly drilling
through the last part of the hole.
• Keep the motor running while pulling the
bit out of a drilled hole. This will help
reduce jamming.
• Make sure switch turns drill on and off.
Drilling in wood
Holes in wood can be made with the same
twist drill bits used for metal or with spade
bits. These bits should be sharp and should
be pulled out frequently when drilling to
clear chips from the flutes.
Drilling in metal
Use a cutting lubricant when drilling metals.
The exceptions are cast iron and brass which
should be drilled dry. The cutting lubricants
that work best are sulfurized cutting oil or
lard oil.
