12
English
LIMBING THICK BRANCHES
When limbing thick branches, the guide bar may get pinched easily.
Branches under tension often snap up, so cut troublesome branches
in small steps. Apply the same principles as for cross cutting. Think
ahead and be aware of the possible consequences of all your
actions.
CROSS CUTTING/BUCKING
Before starting to cut through the log, try to imagine what is going to
happen. Look out for stresses in the log and cut through it in such a
manner that the guide bar will not get pinched.
CROSS CUTTING LOGS, PRESSURE ON TOP
Take a fi rm stance. Begin with an upper cut. Do not cut too deeply,
about 1/3 of the log diameter is enough. Finish with a bottom cut.
The saw cuts should meet. (Fig. 24)
28. Relieving cut
29. Cross cut
30. Pressure on top
31. Pressure side
32. Tension side
33. Relative depth of saw cuts
THICK LOG, LARGER THAN GUIDE BAR LENGTH
Begin by cutting on the opposite side of the log. Pull the saw towards
you, followed by previous procedure. (Fig. 25)
If the log is lying on the ground make a boring cut to avoid cutting into
the ground. Finish with a bottom cut. (Fig. 26)
WARNING
KICKBACK DANGER
Do not attempt a boring cut if you are not properly trained. A
boring cut involves the use of the nose of the guide bar and can
result in kickback.
CROSS CUTTING LOGS, PRESSURE ON BOTTOM
Take a fi rm stance. Begin with a bottom cut. The depth of the cut
should be about 1/3 of the log diameter.
Finish with an upper cut. The saw cuts should meet. (Fig. 27)
34. Relieving cut
35. Cross cut
36. Pressure on bottom
37. Tension side
38. Pressure side
39. Relative depth of saw cuts
THICK LOG, LARGER THAN GUIDE BAR LENGTH
Begin by cutting on the opposite side of the log. Pull the saw towards
you, followed by previous procedure. Make a boring cut if the log is
close to the ground. Finish with a top cut. (Fig. 28)
WARNING
KICKBACK DANGER
Do not attempt a boring cut if you are not properly trained. A
boring cut involves the use of the nose of the guide bar and can
result in kickback. (Fig. 29)
IF THE SAW GETS STUCK
Stop the engine. Raise the log or change its position, using a thick
branch or pole as a lever. Do not try to pull the saw free. If you do,
you can deform the handle or be injured by the saw chain if the saw
is suddenly released.
MAINTENANCE
MAINTENANCE, REPLACEMENT OR REPAIR OF THE EMISSION
CONTROL DEVICES AND SYSTEM MAY BE PERFORMED BY ANY
NON-ROAD ENGINE REPAIR ESTABLISHMENT OR INDIVIDUAL.
Carburetor adjustment (Fig. 30)
In the carburetor, fuel is mixed with air. When the engine is test run at
the factory, the carburetor is adjusted. A further adjustment may be
required, according to climate and altitude. The carburetor has one
adjustment possibility:
T = Idle speed adjustment screw.
Idle speed adjustment (T)
Check that the air fi lter is clean. When the idle speed is correct, the
cutting attachment will not rotate. If adjustment is required, close
(clockwise) the T-screw, with the engine running, until the cutting
attachment starts to rotate. Open (counter-clockwise) the screw
until the cutting attachment stops. You have reached the correct idle
speed when the engine runs smoothly in all positions well below the
rpm when the cutting attachment starts to rotate.
If the cutting attachment still rotates after idle speed adjustment,
contact Hitachi Authorized Service Centers.
WARNING
When the engine is idling the cutting attachment must under no
circumstances rotate.
NOTE
Do not touch the High speed adjustment (H) and the Low speed
adjustment (L).
Those are only for Hitachi Authorized Service Centers.
If you rotate them, It will cause a serious damage to the machine.
Air fi lter (Fig. 31)
The air fi lter (40) must be cleaned from dust and dirt in order to avoid:
○ Carburetor malfunctions.
○ Starting problems.
○ Engine power reduction.
○ Unnecessary wear on the engine parts.
○ Abnormal fuel consumption.
Clean the air fi lter daily or more often if working in exceptionally
dusty areas.
Remove the air fi lter cover (41) and the fi lter (40).
Rinse them in warm soap suds. Check that the fi lter is dry before
reassembly. An air fi lter that has been used for some time cannot be
cleaned completely. Therefore, it must regularly be replaced with a
new one. A damaged fi lter must always be replaced.
Spark plug (Fig. 32)
The spark plug condition is infl uenced by:
○ An incorrect carburetor setting.
○ Wrong fuel mixture (too much oil in the gasoline)
○ A dirty air fi lter.
○ Hard running conditions (such as cold weather).
These factors cause deposits on the spark plug electrodes, which
may result in malfunction and starting diffi culties. If the engine is
low on power, diffi cult to start or runs poorly at idling speed, always
check the spark plug fi rst. If the spark plug is dirty, clean it and check
the electrode gap. Readjust if necessary. The correct gap is 0.6 mm.
The spark plug should be replaced after about 100 operation hours
or earlier if the electrodes are badly eroded.
NOTE
In some areas, local law requires using a resistor spark plug
to suppress ignition signals. If this machine was originally
equipped with resistor spark plug, use same type of spark plug
for replacement.
Oiler port (Fig. 33)
Clean the chain oiler port (42) whenever possible.
Guide bar (Fig. 34)
Before using the machine, clean the groove and oiler port (43) in the
bar with the special gauge off ered as an optional accessory.
Side case (Fig. 35)
Always keep the side case and drive area clean of saw dust and
debris. Periodically apply oil or grease to this area to protect from
corrosion as some trees contain high levels of acid.
Fuel fi lter (Fig. 36)
Remove the fuel fi lter from the fuel tank and thoroughly wash it in
solvent. After that, push the fi lter into the tank completely.
NOTE
If the fi lter is hard due to dust and dirt, replace it.
Chain oil fi lter (Fig. 37)
Remove the oil fi lter and thoroughly wash it in solvent.
Cleaning the cylinder fi ns (Fig. 38)
When wood chips are caught between cylinder fi ns (44), the engine
may overheat, resulting in lower output. To avoid this, always keep
cylinder fi ns and fan case clean.
