![Black & Decker ASD18KB [7/76] Additional safety instructions for batteries and chargers](/img/pdf.png)
Black & Decker ASD18KB [7/76] Additional safety instructions for batteries and chargers
![BLACK & DECKER ASD18KB [7/76] Additional safety instructions for batteries and chargers](/views2/1640729/page7/bg7.png)
Additional safety instructions for
batteries and chargers
Batteries
• Never attempt to open for any reason.
• Do not expose the battery to water.
• Do not store in locations where the
temperature may exceed 40 °C.
• Charge only at ambient temperatures
between 10 °C and 40 °C.
• Charge only using the charger provided
with the tool.
• When disposing of batteries, follow the
instructions given in the section
"Protecting the environment".
Do not attempt to charge damaged
batteries.
Chargers
• Use your BLACK+DECKER charger only
to charge the battery in the tool with
which it was supplied. Other batteries
could burst, causing personal injury and
damage.
• Never attempt to charge
non-rechargeable batteries.
• Have defective cords replaced
immediately.
• Do not expose the charger to water.
• Do not open the charger.
• Do not probe the charger.
The charger is intended for indoor
use only.
Read the instruction manual before
use.
Electrical safety
Your charger is double insulated;
therefore no earth wire is required.
Always check that the mains voltage
corresponds to the voltage on the
rating plate. Never attempt to replace
the charger unit with a regular mains
plug.
• If the supply cord is damaged, it must be
replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
Features
This tool includes some or all of the
following features.
1. Variable speed switch
2. Forward/reverse slider
3. Drill mode selector
4. Screwdriver mode selector
5. State of charge indicator
6. Single sleeve chuck
7. Bit holder
8. LED work light
Fig. A
9. Battery
10. Charger
11. Charge Indicator
Assembly
Warning! Before assembly, remove the
battery from the tool.
Fitting and removing the battery (fig. B)
• To fit the battery (9), line it up with the
receptacle on the tool. Slide the battery
into the receptacle and push until the
battery snaps into place.
• To remove the battery, push the release
button (12) while at the same time pulling
the battery out of the receptacle.
Fitting and removing a drill bit or
screwdriver bit
This tool is fitted with a keyless chuck to
allow for an easy exchange of bits.
• Lock the tool by setting the forward/
reverse slider (2) to the centre position.
• Open the ssingle sleeve chuck (6) by
turning it.
7
ENGLISH
(Original instructions)
