ENGLISH en
13
"AUF, RELEASE". The dust collected falls from
the keyless chuck.
7.8 Unscrewing chuck
Fig. H
Employ the same procedure when attaching the
chuck, except in reverse order.
7.9 Chuck with quick bit change system (for
BS 14.4 LT Quick, BS 18 LT Quick)
Fig. I
To remove: Push the interlock ring forward (a),
advance and pull off the chuck (b).
To mount: Push the interlock ring forward and
move the chuck as far as the limit stop on the drill
spindle.
7.10 Attaching the belt hook (depending on
machine features)/bit depot (depending
on machine features)
Fig. J
Attach the belt hook to the left (6), as shown.
Attach the bit depot to the right (5), as shown.
8.1
The machine's multifunctional monitoring
system
If the machine switches off automatically, the
machine electronics have activated automatic
protection mode. A warning signal sounds (contin-
uous beeping). The beeping stops after a maximum
of 30 seconds or when the trigger (12) is released.
In spite of this protective function, overloading
is still possible with certain applications and
can result in damage to the machine.
Causes and remedies:
1. Battery pack almost empty
Fig. A, B (The
electronics protect the battery pack against
damage through total discharge).
If one LED is flashing (9), the battery pack is
almost flat. If necessary, press the (8) button
and check the LEDs (9) to see the charge level.
If the battery pack is almost flat, it must be
recharged.
2. Long continuous overloading of the machine will
activate the temperature cut-out.
Leave the machine or battery pack to cool.
Note: If the battery pack feels very warm, the
pack will cool more quickly in an "AIR COOLED"
charger.
Note: The machine will cool more quickly if you
operate it at idling speed.
3. Metabo safety shutdown: The machine was
SWITCHED OFF automatically. If the slew rate
of the current is too high (for example, if the
machine suddenly seizes or kickback occurs),
the machine switches off. Switch off the machine
at the trigger (12). Switch it on again and
continue to work as normal. Try to prevent the
machine from seizing.
Switch off the machine at the trigger (12). Then
continue working as normal. Try to prevent the
machine from seizing.
Only use original Metabo battery packs and Metabo
accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating instruc-
tions.
Fitting the angle drilling attachment
Fig. K.
For a complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out
by qualified electricians ONLY!
If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
You can download spare parts lists from
www.metabo.com.
Do not allow battery packs to come into contact with
water!
To protect the environment, do not dispose of
power tools or battery packs in household
waste. Observe national regulations on
separated collection and recycling of disused
machines, packaging and accessories.
Before disposal, discharge the battery pack in the
power tool. Prevent the contacts from short-circu-
iting (e. g. by protecting them with adhesive tape).
Fig. L. We reserve the right to make technical
improvements.
U = Voltage of battery pack
n
0
= No-load speed
Tightening torque for screwing:
M
1
= Soft screwing application (wood)
M
3
= Hard screwing application (metal)
M
4
= Adjustable torque
Max. drill diameter:
D
1 max
= in steel
D
2 max
= in softwood
D
3 max
= in concrete
s = Max. impact rate
m = Weight (with smallest battery pack)
G = Spindle thread
D
max
= Chuck clamping range
Measured values determined in conformity with
EN 60745.
Direct current
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
8. Troubleshooting
9. Accessories
10. Repairs
11. Environmental Protection
12. Technical specifications
