2. The angled “flats” on the back of the molding must rest
squarely on the fence and table of the saw.
INSIDE CORNER:
Left side
1. Mitre right at 45°
2. Save the right side of cut
Right side
1. Mitre left at 45°
2. Save left side of cut
OUTSIDE CORNER:
Left side
1. Mitre left at 45°
2. Save the right side of cut
Right side
1. Mitre right at 45°
2. Save left side of cut
ALWAYS MAKE DRY RUNS TO CHECK FOR CLEARANCE
AND CORRECTNESS OF CUTS.
Special Cuts
NEVER MAKE ANY CUTS UNLESS THE MATERIAL IS
SECURED ON THE TABLE AND AGAINST THE FENCE.
Aluminum Cutting (Carbide tipped blade only)
Aluminum extrusions such as those used when making
aluminum screens and storm windows can easily be cut with
your saw using the proper blade designed for non-ferrous
metal cutting. Position the material so that you will be cutting
the thinnest cross section, as shown in Figure 9.
Figure 10 illustrates the wrong way to cut these extrusions.
Use a wax lubricant when cutting aluminum such as
Johnson’s Stick Wax No.140. Apply the stick wax directly to
the saw blade before cutting. Never apply stick wax to a
moving blade.
The wax, available at most hardware stores and industrial
mill supply houses, provides proper lubrication and keeps
chips from adhering to the blade.
Be sure to properly secure work. Certain workpieces, due to
their size, shape or surface finish, may require the use of a
clamp, jig or fixture to prevent movement during the cut.
Bowed Material
When cutting bowed material always position it as shown in
Figure 11 and never like that shown in Figure 12. Positioning
the material incorrectly will cause it to pinch the blade near
the completion of the cut.
Cutting Plastic Pipe and other round cross-sectional
material
Plastic pipe can be easily cut with your saw. It should be cut
just like wood and clamped or held firmly to the fence to
keep it from rolling particularly when making angle cuts.
Carrying the tool
1. Lower the cutting head and push in the lock pin (10)
2. Carry the mitre saw with the carrying handles (11).
Warning! Do not carry the machine by the guard.
DURING USE
• If the saw blade becomes blocked, switch off the tool
immediately and disconnect the plug; only then remove
the wedged workpiece
• In case of jamming or electrical or mechanical
malfunction, immediately switch off the tool and
disconnect the plug
Maintenance
(PERFORM ALL MAINTENANCE WITH MITRE SAW
UNPLUGGED.)
1. All bearings are sealed. They are lubricated for life and
need no further maintenance.
2. Periodically clean all dust and wood chips from around
AND UNDER the base and the rotary table. Even though
slots are provided to allow debris to pass through, some
dust will accumulate.
3. The brushes are designed to give you several years of
use. If they ever need replacement follow the instructions
in this manual or return the tool to the nearest service
center for repair.
Important
To assure product SAFETY and RELIABILITY, repairs,
maintenance and adjustment (including brush inspection and
replacement) should be performed by authorized service
centers or other qualified service organizations, always using
identical replacement parts.
11
ENGLISH
(Original instructions)
