Stanley STSM1510-B9 [8/44] English

ENGLISH

(Original instructions)

Speciﬁcations

Capacity of cut

47° mitre left and right

47° bevel left

0° mitre -Max. Height 3-1/2” -Max. Width 5-1/2”

45° mitre -Max. Height 3-1/2” -Max. Width 4-1/8”

45° bevel -Max. Height 2-1/2” -Max. Width 5-1/2”

Bench Mounting

Bench mounting holes (8) are provided in all four feet to

facilitate bench mounting, as shown in Figure 1. (Two

different sized holes are provided to accommodate different

sizes of screws. Use either hole, it is not necessary to use

both.) Always mount your saw ﬁrmly to prevent movement.

To enhance the tool’s portability, it can be mounted to a

piece of 1/2" or thicker plywood which can then be clamped

to your work support or moved to other job sites and

reclamped.

NOTE: If you elect to mount your saw to a piece of plywood,

make sure that the mounting screws don’t protrude from the

bottom of the wood. The plywood must sit ﬂush on the work

support. When clamping the saw to any work surface, clamp

only on the clamping bosses where the mounting screw

holes are located. Clamping at any other point will interfere

with the proper operation of the saw.

CAUTION: To prevent binding and inaccuracy, be

sure the mounting surface is not warped or

otherwise uneven. If the saw rocks on the surface, place a

thin piece of material under one saw foot until the saw sits

ﬁrmly on the mounting surface.

Installing a New Saw Blade

(UNPLUG THE MITRE SAW)

DO NOT USE FERROUS METAL or masonry cutting blades

in this saw

• Loosen hex bolt on center cover counter clockwise with

box wrench.

• Lift up the safe cover and center cover.

• Press down the lock to lock spindle.

• Loosen hex bolt clockwise with box wrench, then

dismount the bolt and ﬂange.

• Mount the blade of saw on spindle. Make sure that the

arrow direction on surface of saw blade is same as one

of the cover.

Note: There are two different internal diameters of cutter in

inner plate which have steel stamp marked 25.4mm 16mm.

When mounting, the outer diameter of inner plate must be

correspondent with the internal diameter of saw blade.

• Mount ﬂange and hex bolt.

• Press axle lock and tighten hex bolt counter clock wise

with box wrench ﬁrmly, then tighten hex bolt clockwise to

ﬁx centre cover.

Note: Only use attached wrench when mounting or

dismounting saw blade. When dismounting saw blade, lift up

safe cover and centre cover. Loosen hex bolt with box

wrench and disassemble hex bolt, ﬂange and saw blade.

NEVER DEPRESS THE SPINDLE LOCK PIN WHILE THE

BLADE IS ROTATING.

• Be sure to hold the guard bracket down and ﬁrmly

tighten the guard bracket screw when you ﬁnish installing

the saw blade. Failure to do so will cause serious

damage to the saw.

Assembling and Adjusting Your Saw

PERFORM ALL ASSEMBLY WITH SAW UNPLUGGED.

Attach Mitre Clamp Handle

Remove the mitre clamp handle (4) from the plastic parts

bag and carefully thread it into the bracket in the front of the

saw.

Attaching Dust Bag

A zippered cloth dust bag is included with your saw. To

attach the bag, ﬁt the plastic opening ﬁrmly over the dust

spout (9).

NOTE: The saw can also be used with a vacuum cleaner

hose attached to the dust spout or without any attachment.

Adjustments

PERFORM ALL ADJUSTMENTS WITH THE MITRE SAW

UNPLUGGED

NOTE: Your mitre saw is fully and accurately adjusted at the

factory at the time of manufacture. If readjustment due to

shipping and handling or any other reason is required, follow

the steps below to adjust your saw.
