ENGLISH en
13
of the footplate (6) on the workpiece. Hold the
operating jigsaw firmly and guide slowly
downwards. Once the saw blade has penetrated
the workpiece, the pendulum motion can be
activated.
In thicker workpieces, a hole for inserting the saw
blade must be drilled first.
Only use original Metabo battery packs and Metabo
accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
Fit accessories securely. If the machine is operated
in a holder: secure the machine well. Loss of control
can cause personal injury.
See page 4.
A Circular-cutting and parallel guide
B Protective plate (prevents workpieces with
sensitive surfaces from becoming scratched)
CChargers
D Battery packs with different capacities.
Use battery packs only with voltage suitable for
your power tool.
10.1 Attaching the circular-cutting and
parallel guide
For sawing circles (dia. 100 - 360 mm) and making
cuts parallel with edges (max. 210 mm).
Attach circular guide (see Fig. I)
- Slide the rod on the circular-cutting and parallel
guide sideways into the footplate (centre point (c)
faces downwards).
- Set the desired radius (d).
- Tighten screw (b).
- Turn the button in such a way that the rear centre
point (c) in direction of sawing is extended. Insert
it into the centre of the circle.
Attach parallel guide (see Fig. II)
- Slide the rod on the circular cutting and parallel
guide sideways into the footplate
(the centre point (c) faces upwards).
- Set the dimension (e)
- Tighten screw (b).
In order to minimise saw blade drifting, we
recommend using extra-thick saw blades: 6.23694,
6.23679, 6.23685
For a complete range of accessories, see
www.metabo.com or the catalogue.
Repairs to electrical tools must ONLY be
carried out by qualified electricians!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: never dispose of
power tools in your household waste! Used
power tools must be collected separately and
handed in for environmentally compatible recycling
in accordance with European Directive 2012/19/EU
on waste electrical and electronic equipment and its
implementation in national legal systems.
Explanatory notes on the specifications on page 3.
Subject to change in accordance with technical
progress.
T
1
=Maximum material thickness in wood
T
2
=Maximum material thickness in non-
ferrous metals
T
3
=Maximum material thickness in sheet
steel
n
0
=Stroke rate at idle speed
P
1
=Rated input power
P
2
=Power output
m =Weight with smallest battery pack
Measured values determined in conformity with
EN 62841.
Permitted ambient temperature during operation:
-20 °C to 50 °C (limited performance with
temperatures below 0 °C). Permitted ambient
temperature for storage: 0 °C to 30 °C
Direct current
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. The actual load may be higher
or lower depending on the operating conditions, the
condition of the power tool or the accessories.
Please allow for breaks and periods when the load
is lower for assessment purposes. Arrange
protective measures for the user, such as
organisational measures based on the adjusted
estimates.
Vibration total value
(vector sum of three directions)
determined in accordance with EN 62841:
a
h,CM
=Vibration emission value
(Sawing sheet metal)
a
h,CW
=Vibration emission value
(Sawing wood)
K
h,...
=Uncertainty (vibration)
Typical A-effective perceived sound levels
:
L
pA
=Sound-pressure level
L
WA
=Acoustic power level
K
pa
, K
WA
= Uncertainty
During operation the noise level can exceed
80 dB(A).Wear ear protectors!
10. Accessories
11. Repairs
12. Environmental Protection
13. Technical Specifications
