Parts List

Item P/N Description Qty.

1 MPA0040 RETAINING RING 1

2 MPA0021 BEARING 1

3 MPB0017 REAR ENDPLATE 1

4 MPA0005 CYLINDER ASSEMBLY 1

5 MPA0042 O-RING 1

6 MPB0005 ROTOR 1

7 MPA0010 VANE 5

8 MPA0041 KEY 1

9 MPB0016 FRONT ENDPLATE 1

10 MPA0019 BEARING 1

11 MPA0045 O-RING 1

12 MPA0001 LOCK RING 1

MPB0277 5 mm (3/16 in.) ORBIT AirSHIELD™ SHAFT BALANCER FOR 125 mm (5 in.) PADS 1

MPB0278 5 mm (3/16 in.) ORBIT AirSHIELD™ SHAFT BALANCER FOR 150 mm (6 in.) PADS 1

MPB0279 2.5 mm (3/32 in.) ORBIT AirSHIELD™ SHAFT BALANCER FOR 125 mm (5 in.) PADS 1

MPB0280 2.5 mm (3/32 in.) ORBIT AirSHIELD™ SHAFT BALANCER FOR 150 mm (6 in.) PADS 1

14 MPA0122 FILTER 1

15 MPA0121 CHECK VALVE 1

16 MPA0120 RETAINER 1

17 N/A

18 MPA0938 DOUBLE ROW BEARING 1

19 MPA0016 SPACER 1

20 MPA0017 WASHER 1

21 MPA0018 RETAINING RING 1

22 MPB0018 SPINDLE 1

MPA1699 LEVER FOR 12,000 rpm, 125 mm (5 in.) / 150 mm (6 in.) PADS 5 mm (3/16 in.) ORBIT MACHINES 1

MPA1698 LEVER FOR 12,000 rpm, 125 mm (5 in.) / 150 mm (6 in.) PADS 2.5 mm (3/32 in.) ORBIT MACHINES 1

24 MPA0031 PIN 1

MPA0288 65 mm (2 1/2 in.) GRIP (Optional) OPTIONAL

MPA0289 70 mm (2 3/4 in.) GRIP (Optional) OPTIONAL

MPA0290 75 mm (3 in.) GRIP (Standard)) 1

26 MPA0015 SLEEVE 1

27 MPA0244 HOUSING 1

28 MPA0008 VALVE STEM ASSEMBLY 1

29 MPA0043 O-RING 1

30 MPB0014 SPEED CONTROL 1

31 MPA0039 RETAINING RING 1

32 MPB0012 125/150 mm (5/6 in.) NON-VACUUM SHROUD 1

33 MPC0012 SuperVAC™ SHROUD for 125 mm (5 in.) Delta, TE, LP and Screen Abrasive pads 1

34 MPC0073 SuperVAC™ SHROUD for 150 mm (6 in.) Screen Abrasive and LP Pads 1

35 MPA0022 24 mm PAD WRENCH (supplied with each tool) 1

36 NA SEE LITERATURE FOR PADS (type/size determined by model) 1

37 MPA0062 INTERNAL MUFFLER (for 12,000 rpm Machines) 1

38 MPA0068 MUFFLER INSERT(for 12,000 rpm Machines) 1

39 MPA0166

MUFFLER HOUSING 1

40 MPA0009 SEAT 1

41 MPA0007 VALVE 1

42 MPA0014 VALVE SPRING 1

43 MPA0013 INLET BUSHING 1

44 MPA0044 O-RING 2

45 MPA0006 DB RETAINER 1

46 MPA0778 28mm (1 in.) HOSE SEAL 1

47 MPA0410 28 mm (1 in.) HOSE SuperVAC™ DB SWIVEL EXHAUST ASSEMBLY (Standard for DB)) 1

MPA0856 19mm (3/4 in.) HOSE SEAL TAG OPTIONAL

MPA0931 28mm (1 in.) HOSE SEAL TAG 1

49 MPA0854 19mm (3/4 in.) HOSE SEAL OPTIONAL

50 MPA0409 19 mm (¾ in.) HOSE SuperVAC™ DB SWIVEL EXHAUST ASSEMBLY (Optional for DB) OPTIONAL

51 MPC0108 SuperVAC™ DB EXHAUST ADAPTER (for use with SuperVAC™ Shroud) 1

MPA0300

Ø 19 mm (¾ in.) VAC HOSE TO Ø 19 mm (¾ in.) x Ø 28 mm (1 in.) HOSE ADAPTER COUPLING AND AIRLINE

ASSEMBLY INCLUDES: MPA0200 Ø 19 mm (¾ in.) x 1.5 m (5 ft.) Vacuum Hose, MPB0088 19 mm (¾ in.) Hose x

28 mm (1 in.) Hose Adapter, MPA0302 Ø 6.3 mm (¼ in.) x 1.5 m (5 ft.) Airline with Fittings, MPA0301 Bungee for Ø

6.3 mm (¼ in.) Airline & Ø 19 mm (¾ in.) Vacuum Hose (5)

OPTIONAL

MPA0392

Ø 28 mm (1 in.) VAC HOSE TO Ø 28 mm (1 in.) x Ø 38 mm (1 ½ in.) FRICTION FIT ADAPTER AND AIRLINE

ASSY. (Optional) INCLUDES: MPA0034 Ø 28 mm (1 in.) x 1.8 m (6 ft.) Vacuum Hose, MPB0092 Ø 28 mm (1 in.)

Hose Thread x Ø 38 mm (1 ½ in.) Friction Fit Adapter, MPA0033 Ø 6.3 mm (¼ in.) x 1.8 m (6 ft.) Airline with Fittings,

MPA0027 Bungee for Ø 6.3 mm (¼ in.) Airline & Ø 28 mm (1 in.) Vacuum Hose (5)

OPTIONAL

MPA0412

Ø 28 mm (1 in.) VAC HOSE TO Ø 28 mm (1 in.) DOUBLE BAG FITTING AND AIRLINE ASSY. (Standard for DB)

INCLUDES: MPA0034 Ø 28 mm (1 in.) x 1.8 m (6 ft.) Vacuum Hose, MPB0123 Ø 28 mm (1 in.) Hose to Double Bag

Vacuum Fitting, MPA0033 Ø 6.3 mm (¼ in.) x 1.8 m (6 ft.) Airline with Fittings, MPA0027 Bungee for Ø 6.3 mm (¼

in.) Airline & Ø 28 mm (1 in.) Vacuum Hose (5)

MPA0411

Ø 19 mm (¾ in.) VAC HOSE TO Ø 19 mm (¾ in.) DOUBLE BAG FITTING AND AIRLINE ASSEMBLY (Optional

for DB) INCLUDES: MPA0200 Ø 19 mm (¾ in.) x 1.5 m (5 ft.) Vacuum Hose, MPB0133 Ø 19 mm (¾ in.) Hose To

Double Bag Vacuum Fitting, MPA0302 Ø 6.3 mm (¼ in.) x 1.5 m (5 ft.) Airline with Fittings, MPA0301 Bungee for Ø

6.3 mm (¼ in.) Airline & Ø 19 mm (¾ in.) Vacuum Hose (5)

OPTIONAL

54 MPA0099 SuperVAC™ CV 28 mm (1 in.) SWIVEL EXHAUST ASSEMBLY (Standard for CV) 1

55 MPA0048 NUT 1

56 MPA0205 SuperVAC™ CV 19 mm (¾ in.) SWIVEL EXHAUST ASSEMBLY (Optional for CV) OPTIONAL

57 MPA0047 WASHER 1

58 MPA0769 SCREW 1

59 MPA0465 10 PACK OF VACUUM BAG INSERTS 1

60 MPA0658 VACUUM BAG 1

61 MPA2541 FRONT BEARING DUST SHIELD 1

62 MPA2542 SPINDLE BEARING DUST SHIELD 1
